2. TYPE CLASSIFICATIONS
2.1 Type
The product is categorized according to the naming plan indicated below.
MP-20
Model Name
Number of columns (default font)
20 : 20 columns/384 dots per line
2.2 AC adapter
Please use the exclusive adapter indicated below.
250115288 (AC 100-240V)
2.3 Specifications
Printing method Thermal dot line printing
Printing width 48 mm
Number of dots/line 384
Dots density 8 dots/mm
Printing speed 18 mm/second
1
Feeding speed 24 mm/second
Standard paper roll size (W x L)
57 mm
×
36 m (Thermal)
Dia = 57 mm
Interface Serial Interface (RS-232C)
Baud Rate, 9600
Data Bits, 8
Parity, None
Stop Bits, 1
Power DC9V / 2.8A
Current consumption Printing: 800 mA
Feeding: 300 mA
Stand By: 80 mA
Weight Approx. 360g (Paper roll excluded)
Dimension (W x D x H)
120 mm
×
170 mm
×
92 mm
Operation temp. 0 to 50 °C
Storage temp. -25 to 65 °C
Fonts available Arial Narrow 14, Arial Narrow 20, Arial 14 Bold,
Arial 20 Bold, Lucida 16 Bold, Courier 20 Bold,
CHIBLACK 24
Default font CHIBLACK 24
2
Barcode Code 39
Max. Printable label size (W x L)
50 mm
×
100 mm
Error conditions detected Paper out, Head up, Overheat
1
Version 1.06 or higher only. Lower versions print at 10 mm/second.
2
Version 1.08 or higher only. Lower versions default to Lucida 16 Bold.
