3.6.26 CALCX (Calculate using the X Register)
This instruction is very similar to CALC, but the second operand comes from the X register. The X register
can be loaded with the LOAD or the SWAP type of this instruction. The result is written back to the
accumulator for further processing like comparisons or data transfer. This command is mainly intended for
use in standalone mode.
Related commands: CALC, COMP, JC, AAP, AGP, GAP, GGP, GIO.
Mnemonic: CALCX <operation>
Binary Representation
Instruction Type Motor/Bank Value
33 0 ADD – add X register to accumulator 0 (don’t care) 0 (don’t care)
1 SUB – subtract X register from accumulator
2 MUL – multiply accumulator by X register
3 DIV – divide accumulator by X register
4 MOD – modulo divide accumulator by X register
5 AND – logical and accumulator with X register
6 OR – logical or accumulator with X register
7 XOR – logical exor accumulator with X register
8 NOT – logical invert X register
9 LOAD – copy accumulator to X register
10 SWAP – swap accumulator and X register
Reply in Direct Mode
Status Value
100 - OK don’t care
Example
Multiply accumulator and X register.
Mnemonic: CALCX MUL
