3.6.8 GGP (Get Global Parameter)
All global parameters can be read with this function. Global parameters are related to the host interface,
peripherals or application specific variables. The different groups of these parameters are organized in
banks to allow a larger total number for future products. Currently, bank 0 is used for global parameters,
and bank 2 is used for user variables. Bank 3 is used for interrupt configuration.
Info
For a table with parameters and values which can be used together with this
command please refer to section 5.
Internal function:
The global parameter specified by the type and bank number will be copied to the
accumulator register.
Related commands: SGP, AGP.
Mnemonic: GGP <parameter number>, <bank>
Binary Representation
Instruction Type Motor/Bank Value
10 see chapter 5 0/2/3 0 (don’t care)
Reply in Direct Mode
Status Value
100 - OK value read by this command
Example
Get the serial address of the device.
Mnemonic: GGP 66, 0.
Binary Form of GGP 66, 0
Field Value
Target address 01
h
Instruction number 0A
h
Type 42
h
Motor/Bank 00
h
Value (Byte 3) 00
h
Value (Byte 2) 00
h
Value (Byte 1) 00
h
Value (Byte 0) 00
h
Checksum 4D
h
