TMCM-3212 TMCL
™
Firmware Manual • Firmware Version V1.07 | Document Revision V1.04 • 2017-JUN-08
18 / 103
Interrupt Processing Commands
Mnemonic Command number Meaning
EI 25 Enable interrupt
DI 26 Disable interrupt
VECT 37 Set interrupt vector
RETI 38 Return from interrupt
Table 11: Interrupt Processing Commands
3.5.6.1 Interrupt Types
There are many different interrupts in TMCL, like timer interrupts, stop switch interrupts, position reached
interrupts, and input pin change interrupts. Each of these interrupts has its own interrupt vector. Each
interrupt vector is identified by its interrupt number. Please use the TMCL include file Interrupts.inc in
order to have symbolic constants for the interrupt numbers. Table 12 show all interrupts that are available
on the TMCM-3212.
Interrupt Vectors
Interrupt number Interrupt type
0 Timer 0
1 Timer 1
2 Timer 2
3 Target position reached 0
4 Target position reached 1
5 Target position reached 2
15 stallGuard axis 0
16 stallGuard axis 1
17 stallGuard axis 2
21 Deviation axis 0
22 Deviation axis 1
23 Deviation axis 2
27 Left stop switch 0
28 Right stop switch 0
29 Left stop switch 1
30 Right stop switch 1
31 Left stop switch 2
32 Right stop switch 2
39 Input change 0
40 Input change 1
