PD-1160 TMCL
™
Firmware Manual • Firmware Version V1.42 | Document Revision V1.06 • 2018-JAN-09
18 / 113
Motion Commands
Mnemonic Command number Meaning
ROL 2 Rotate left
ROR 1 Rotate right
MVP 4 Move to position
MST 3 Motor stop
SCO 30 Store coordinate
CCO 32 Capture coordinate
GCO 31 Get coordinate
Table 6: Motion Commands
3.6.2 Parameter Commands
These commands are used to set, read and store axis parameters or global parameters. Axis parameters
can be set independently for each axis, whereas global parameters control the behavior of the module
itself. These commands can also be used in direct mode and in standalone mode.
Parameter Commands
Mnemonic Command number Meaning
SAP 5 Set axis parameter
GAP 6 Get axis parameter
STAP 7 Store axis parameter
RSAP 8 Restore axis parameter
SGP 9 Set global parameter
GGP 10 Get global parameter
STGP 11 Store global parameter
RSGP 12 Restore global parameter
Table 7: Parameter Commands
3.6.3 Branch Commands
These commands are used to control the program flow (loops, conditions, jumps etc.). Using them in direct
mode does not make sense. They are intended for standalone mode only.
