PD-1160 TMCL
™
Firmware Manual • Firmware Version V1.42 | Document Revision V1.06 • 2018-JAN-09
16 / 113
3.5 TMCL Command Overview
This sections gives a short overview of all TMCL commands.
3.5.1 TMCL Commands
Overview of all TMCL Commands
Command Number Parameter Description
ROR 1 <motor number>, <velocity> Rotate right with specified velocity
ROL 2 <motor number>, <velocity> Rotate left with specified velocity
MST 3 <motor number> Stop motor movement
MVP 4
ABS|REL|COORD, <motor number>,
<position|offset>
Move to position (absolute or relative)
SAP 5
<parameter>, <motor number>,
<value>
Set axis parameter (motion control
specific settings)
GAP 6 <parameter>, <motor number>
Get axis parameter (read out motion
control specific settings)
STAP 7
<parameter>, <motor number>,
<value>
Store axis parameter (store motion
control specific settings)
RSAP 8 <parameter>, <motor number>
Restore axis parameter (restore mo-
tion control specific settings)
SGP 9
<parameter>, <bank number>,
<value>
Set global parameter (module specific
settings e.g. communication settings
or TMCL user variables)
GGP 10 <parameter>, <bank number>
Get global parameter (read out mod-
ule specific settings e.g. communica-
tion settings or TMCL user variables)
STGP 11 <parameter>, <bank number>
Store global parameter (TMCL user
variables only)
RSGP 12 <parameter>, <bank number>
Restore global parameter (TMCL user
variables only)
RFS 13
<START|STOP|STATUS>, <motor num-
ber>
Reference search
SIO 14
<port number>, <bank number>,
<value>
Set digital output to specified value
GIO 15 <port number>, <bank number> Get value of analog/digital input
CALC 19 <operation>, <value> Process accumulator and value
COMP 20 <value> Compare accumulator with value
JC 21 <condition>, <jump address> Jump conditional
JA 22 <jump address> Jump absolute
CSUB 23 <subroutine address> Call subroutine
