PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
75 / 86
Object Description
Index Name Object Type Data Type
6071
h
Target Torque Variable SIGNED32
Table 211: Object Description (6071
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Target Torque no -3000 3000 0 [mA] RW
Table 212: Entry Description (6071
h
)
9.1.4 Object 6077
h
: Torque Actual Value
The actual motor current.
Object Description
Index Name Object Type Data Type
6077
h
Torque Actual Value Variable SIGNED32
Table 213: Object Description (6077
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Torque Actual Value no -2147483648 2147483647 0 R
Table 214: Entry Description (6077
h
)
9.1.5 Object 60B2
h
: Torque offset
The actual set torque offset.
Object Description
Index Name Object Type Data Type
60B2
h
Torque offset Variable SIGNED32
Table 215: Object Description (60B2
h
)
