PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
64 / 86
Supported Homing Methods
Method Description
0 No homing (default value for object 6098
h
).
17 Search the left end switch.
18 Search the right end switch.
35
The actual position is used as home position. All position values (objects 6062h, 6063h,
and 6064h) are set to zero, but the motor will not move.
Table 176: Supported CANopen Homing Methods
When using homing methods that need end switch inputs or home switch inputs please take care of their
configuration (object 2005
h
).
8.1.1 Homing Method 17 and 18: Homing without Index Pulse
For these methods the home position only depends on the relevant home or limit switch transitions.
Homing Methods 17 and 18
Method Description
17 Search the left end switch.
18 Search the right end switch.
Table 177: Homing Methods 17 – 21
8.1.2 Homing Method 35: Current Position as Home Position
In this method, the current position shall be taken to be the home position. This method does not require
the drive device to be in operation enabled state.
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
