PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
44 / 86
Bit 7: cyclic synchronous position mode
Bit 8: cyclic synchronous velocity mode
Bit 9: cyclic synchronous torque mode
Bit 10-15: reserved
Bit 16-31: manufacturer-specific
Object Description
Index Name Object Type Data Type
6502
h
Supported Drive Modes Variable UNSIGNED32
Table 113: Object Description (6502
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Supported Drive Modes no 0 4294967295 0 R
Table 114: Entry Description (6502
h
)
6 Profile Position Mode
A target position is applied to the trajectory generator. It is generating a position demand value for the
position control loop described in the position control function.
Please refer to object 6060
h
(section 5.1.6) for information about how to choose an operation mode.
Object 6061
h
(section 5.1.7) shows the operation mode that is set.
6.1 Detailed Object Specifications
The following text offers detailed object specifications. For a better understanding, it is necessary to see
how the state machine works.
