PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
40 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Disable Operation Option Code no 1 1 1 RW
Table 98: Entry Description (605C
h
)
5.1.4 Object 605D
h
: Halt Option Code
This object indicates what action is performed when the halt function is executed. The slow down ramp is
the deceleration value of the used mode of operation. The halt option code always has the value 1 as only
this is supported.
1: Slow down on slow down ramp and stay in operation enabled
Object Description
Index Name Object Type Data Type
605D
h
Halt Option Code Variable SIGNED16
Table 99: Object Description (605D
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Halt Option Code no 1 1 1 RW
Table 100: Entry Description (605D
h
)
5.1.5 Object 605E
h
: Fault Reaction Option Code
This object indicates what action is performed when fault is detected in the power drive system. The slow
down ramp is the deceleration value of the used mode of operation. The fault reaction option code always
has the value 2 as only this is supported.
2: Slow down on quick stop ramp
Object Description
Index Name Object Type Data Type
605E
h
Fault Reaction Option Code Variable SIGNED16
Table 101: Object Description (605E
h
)
