PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
39 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Quick Stop Option Code no 1 6 0 RW
Table 94: Entry Description (605A
h
)
5.1.2 Object 605B
h
: Shutdown Option Code
This object indicates what action is performed if there is a transition from operation enabled state to ready
to switch on state. The shutdown option code always has the value 0 as only this is supported.
0: Disable drive function (switch off the power stage)
Object Description
Index Name Object Type Data Type
605B
h
Shutdown Option Code Variable SIGNED16
Table 95: Object Description (605B
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Shutdown Option Code no 0 0 0 RW
Table 96: Entry Description (605B
h
)
5.1.3 Object 605C
h
: Disable Operation Option Code
This object indicates what action is performed if there is a transition from operation enabled state to
switched on state. The disable operation option code always has the value 1 as only this is supported. The
slow down ramp is the deceleration value of the used mode of operation.
1: Slow down on slow down ramp
Object Description
Index Name Object Type Data Type
605C
h
Disable Operation Option Code Variable SIGNED16
Table 97: Object Description (605C
h
)
