PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
38 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ADC_phase_A no 0 4095 0 R
2 ADC_phase_B no 0 4095 0 R
3 ADC_VSupply no 0 4095 0 R
4 ADC_Temp no 0 4095 0 R
Table 92: Entry Description (270E
h
)
5 Profile specific area
The profile segment contains CiA-402 standard motion control objects. These objects control the motion
control functions of the PD42-x-1670. Since it is not possible to operate the modes in parallel, the user is
able to activate the required function by selecting a mode of operation. The control device writes to the
modes of operation object in order to select the operation mode. The drive device provides the modes
of operation display object to indicate the actual activated operation mode. Controlword, statusword,
and set-points are used mode-specific. This implies the responsibility of the control device to avoid
inconsistencies and erroneous behavior.
The following operating modes (selectable via object 6060
h
, please see 5.1.6) are implemented on the
PD42-x-1670:
• Profile position mode (pp)
• Profile velocity mode (pv)
• Cyclic torque mode (cst)
• Homing mode (hm)
5.1 Detailed object specifications
5.1.1 Object 605A
h
: Quick Stop Option Code
This object indicates what action is performed when the quick stop function is executed. The slow down
ramp is the deceleration value of the used mode of operation. The following quick stop option codes are
supported in the current version of the CANopen firmware:
1: Slow down on slow down ramp and transit into switch on disabled
2: Slow down on quick stop ramp and transit into switch on disabled
5: Slow down on slow down ramp and stay in quick stop active)
6: Slow down on quick stop ramp and stay in quick stop active
Object Description
Index Name Object Type Data Type
605A
h
Quick Stop Option Code Variable SIGNED16
Table 93: Object Description (605A
h
)
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
