PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
35 / 86
Bit Definitions
Bit Description
16 REF_R (Right limit switch)
17 REF_L (Left limit switch)
18 INPUT_0
19 ENABLE
Table 79: Bit Definitions (2702
h
)
Object Description
Index Name Object Type Data Type
2702
h
Device Digital Inputs Variable UNSIGNED32
Table 80: Object Description (2702
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 ro yes – 0
Table 81: Entry Description (2702)
h
4.1.16 Object 2703
h
: Digital Outputs
With this object the digital outputs (general purpose outputs) can be set. Bits 23. . . 16 of sub index 1 switch
the outputs of the module. Bits 23. . . 16 of sub index 2 determine which outputs can be switched. The
number of available digital outputs depends on the module type.
Bit Definitions
Bit Description
16 OUTPUT_0
Table 82: Bit Definitions (2703
h
)
Object Description
Index Name Object Type Data Type
2703
h
Device Digital Outputs Variable ARRAY
Table 83: Object Description (2703
h
)
