PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
34 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ActualAngle no -32768 32767 0 R
2 StepsPerRotation no 0 65535 4096 RW
3 Offset no 0 65535 0 RW
4 Direction no 0 1 0 RW
5 InitMode no 0 2 1 RW
6 InitDelay no 0 10000 1000 [ms] RW
7 InitVelocity no -200000 200000 100 [rpm] RW
Table 76: Entry Description (2080
h
)
4.1.14 Object 2100
h
: Home Offset Display
This object shows the home offset. The value is given in encoder or hall increments.
Object Description
Index Name Object Type Data Type
2100
h
Home Offset Display Variable SIGNED32
Table 77: Object Description (2100
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Home Offset Display no -2147483648 2147483647 0 R
Table 78: Entry Description (2100
h
)
4.1.15 Object 2702
h
: Digital Inputs
Bits 23. . . 16 of this object reflect the states of the general purpose inputs of the module. The number of
available inputs depends on the module type.
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
