PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
33 / 86
4.1.11 Object 2056
h
: Velocity Ramp Mode
An activated ramp allows a defined acceleration for velocity and position mode.
Object Description
Index Name Object Type Data Type
2056
h
Velocity Ramp Mode Variable UNSIGNED8
Table 71: Object Description (2056
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Velocity Ramp Mode no 0 1 1 RW
Table 72: Entry Description (2056
h
)
4.1.12 Object 2060
h
: Open Loop Settings
Object Description
Index Name Object Type Data Type
2060
h
Open Loop Settings Variable Record
Table 73: Object Description (2060
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ActualAngle no -32768 32767 0 R
2 OpenLoopCurrent no 0 7400 2000 [mA] (peak) RW
Table 74: Entry Description (2060
h
)
4.1.13 Object 2080
h
: ABN Encoder Settings
Object Description
Index Name Object Type Data Type
2080
h
ABN Encoder Settings Variable Record
Table 75: Object Description (2080
h
)
