PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
32 / 86
4.1.9 Object 2050
h
: Position Mode Settings
Object Description
Index Name Object Type Data Type
2050
h
Position Mode Settings Variable Record
Table 67: Object Description (2050
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ActualPosition no -2147483648 2147483647 0 RW
2 TargetPosition no -2147483648 2147483647 0 R
3 RampTargetPosition no -2147483648 2147483647 0 R
4 P_Parameter no 0 65535 0 RW
5 PI_Position_Error no -2147483648 2147483647 0 R
6 TargetReachedVelocity no 0 200000 500 [rpm] RW
7 TargetReachedDistance no 0 100000 5 RW
Table 68: Entry Description (2050
h
)
4.1.10 Object 2055
h
: Commutation Mode
Select a commutation mode that fits best to your motor’s sensors.
7 : FOC (encoder)
8 : FOC (controlled)
Object Description
Index Name Object Type Data Type
2055
h
Commutation Mode Variable Record
Table 69: Object Description (2055
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Commutation Mode no 7 8 7 RW
Table 70: Entry Description (2055
h
)
