PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
30 / 86
4.1.6 Object 2020
h
: Limits
Object Description
Index Name Object Type Data Type
2020
h
Limits Variable Record
Table 61: Object Description (2020
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 MaxTorque no 0 3000 7400 [mA] (peak) RW
2 MaxVelocity no 0 200000 4000 [rpm] RW
3 MaxAcceleration no 0 100000 2000 [rpm/s] RW
4 PANdriveTorqueLimit no 0 7400 7400 [mA] RW
Table 62: Entry Description (2020
h
)
4.1.7 Object 2030
h
: Torque Mode Settings
Object Description
Index Name Object Type Data Type
2030
h
Torque Mode Settings Variable Record
Table 63: Object Description (2030
h
)
