PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
29 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Supply Voltage no 0 280 240 [100mV] R
Table 56: Entry Description (200E
h
)
4.1.4 Object 200F
h
: Driver Temperatur
The actual temperature of the motor driver.
Object Description
Index Name Object Type Data Type
200F
h
Driver Temperatur Variable SIGNED32
Table 57: Object Description (200F
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Driver Temperature no -20 120 0 °C R
Table 58: Entry Description (200F
h
)
4.1.5 Object 2010
h
: Motor Settings
Object Description
Index Name Object Type Data Type
2010
h
Motor Settings Variable Record
Table 59: Object Description (2010
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 MotorPoles no 2 254 8 RW
Table 60: Entry Description (2010
h
)
