PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
28 / 86
Bit 2: OVERVOLTAGE
Bit 3: OVERTEMPERATURE
Bit 4: MOTORHALTED
Bit 5: HALLERROR
Bit 6: DRIVER_ERROR
Bit 7: INIT_ERROR
Bit 8: STOP_MODE
Bit 9: VELOCITY_MODE
Bit 10: POSITION_MODE
Bit 11: TORQUE_MODE
Bit 12: EMERGENCYSTOP
Bit 13: FREERUNNING
Bit 14: POSITION_END
Bit 15: MODULE_INITIALIZED
Bit 16: unused
Bit 17: IIT_EXCEEDED
Object Description
Index Name Object Type Data Type
200D
h
Status Flags Variable UNSIGNED32
Table 53: Object Description (200D
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Status Flags no 0 4294967295 0 R
Table 54: Entry Description (200D
h
)
4.1.3 Object 200E
h
: Supply Voltage
The actual supply voltage.
Object Description
Index Name Object Type Data Type
200E
h
Supply Voltage Variable UNSIGNED32
Table 55: Object Description (200E
h
)
