PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
26 / 86
Object Description
Index Name Object Type Data Type
1A00
h
– 1A03
h
Transmit PDO mapping parameter RECORD PDO Mapping
1A00
h
TPDO 1 RECORD PDO Mapping
1A01
h
TPDO 2 RECORD PDO Mapping
1A02
h
TPDO 3 RECORD PDO Mapping
1A03
h
TPDO 4 RECORD PDO Mapping
Table 48: Object Description (1A00
h
)
Entry Description
Sub-index Description Access Value Range Default Value
00
h
Number of
mapped aapli-
cation objects in
PDO
rw 0. . . 3 Index 1A00
h
: 1
Index 1A01
h
: 2
Index 1A02
h
: 2
Index 1A03
h
: 2
01
h
Mapping entry 1 rw UNSIGNED32 Index 1A00
h
: 60410010
h
Index 1A01
h
: 60410010
h
Index 1A02
h
: 60410010
h
Index 1A03
h
: 60410010
h
02
h
Mapping entry 2 rw UNSIGNED32 Index 1A00
h
: 0
Index 1A01
h
: 60610008
h
Index 1A02
h
: 60640020
h
Index 1A03
h
: 606C0020
h
03
h
Mapping entry 3 rw UNSIGNED32 Index 1A00
h
: 0
h
Index 1A01
h
: 0
h
Index 1A02
h
: 0
h
Index 1A03
h
: 0
h
Table 49: Entry Description (1A00
h
)
Before making changes to PDO definitions, first mark the PDO as inactive by setting bit 31 of its COB-ID
(see section 3.1.19). Then, set its number of mapped PDO entries to zero (sub-index 0 of the appropriate
PDO mapping object). Now, the mapppings themself can be changed. After that, set the number of map
objects to the desired value, and finally activate the PDO by clearing bit 31 of its COB-ID.
4 Manufacturer specific area
The manufacturer segment contains manufacturer specific objects. These objects control the special
features of the Trinamic Motion Control device PD42-x-1670.
4.1 Detailed object specifications
