PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
23 / 86
Entry Description
Sub-index Description Access Value Range Default Value
00
h
Largest sub-index
supported
ro 2 2
01
h
COB-ID used by
PDO
rw UNSIGNED32 Index 1400
h
: 200
h
+ Node-ID
Index 1401
h
: 300
h
+ Node-ID
Index 1402
h
: 400
h
+ Node-ID
Index 1403
h
: 500
h
+ Node-ID
02
h
Transmission type rw UNSIGNED8 Index 1400
h
: FF
h
Index 1401
h
: FF
h
Index 1402
h
: FF
h
Index 1403
h
: FE
h
Table 43: Entry Description (1400
h
)
3.1.18 Objects 1600
h
– 1603
h
: Receive PDO Mapping Parameter
These objects contain the mapping parameters for the RPDOs the device is able to receive. The sub-index
00
h
contains the number of valid entries within the mapping record. This number of entries is also the
number of the application variables which shall be received with the corresponding RPDO. The sub-indices
from 01
h
to the number of entries contain the information about the mapped application variables. These
entries describe the PDO contents by their index, sub-index and length.
Object Description
Index Name Object Type Data Type
1600
h
– 1603
h
Receive PDO mapping parameter RECORD PDO Mapping
1600
h
RPDO 1 RECORD PDO Mapping
1601
h
RPDO 2 RECORD PDO Mapping
1602
h
RPDO 3 RECORD PDO Mapping
1603
h
RPDO 4 RECORD PDO Mapping
Table 44: Object Description (1600
h
)
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
