PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
21 / 86
Object Description
Index Name Object Type Data Type
1017
h
Producer heartbeat time Variable UNSIGNED16
Table 36: Object Description (1017
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 rw no UNSIGNED16 0
Table 37: Entry Description (1017
h
)
3.1.15 Object 1018
h
: Identity Object
The object 1018
h
contains general information about the device:
•
The vendor ID (sub-index 01
h
) contains a unique value allocated to each manufacturer. The vendor
ID of Trinamic is 286
h
.
• The manufacturer specific product code (sub-index 2
h
) identifies a specific device version.
•
The manufacturer specific revision number (sub-index 3
h
) consists of a major revision number and a
minor revision number.
Object Description
Index Name Object Type Data Type
1018
h
Identity object Record Identity
Table 38: Object Description (1018
h
)
Entry Description
Sub-index Description Access PDO Mapping Value Range Default Value
00
h
Number of entries ro no 0. . . 3 3
01
h
Vendor ID ro no UNSIGNED32 0286
h
02
h
Product code ro no UNSIGNED32 1670
03
h
Revision number ro no UNSIGNED32 e.g. 20003
h
for version 2.3
Table 39: Entry Description (1018
h
)
3.1.16 Object 1029
h
: Error Behaviour
If a device failure is detected in operational state, the device can be configured to enter alternatively the
stopped state or remain in the current state in case of a device failure. Device failures include the following
errors:
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
