PD42-x-1670 CANopen Firmware Manual Firmware Version V2.0 | Document Revision V1.0 2018-Nov-07
16 / 86
Object Description
Index Name Object Type Data Type
100A
h
Manufacturer Software Version Variable Visible String
Table 17: Object Description (100A
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 ro no Depends on device, e.g. 1.0.
Table 18: Entry Description (100A
h
)
3.1.7 Object 100C
h
: Guard Time
The objects at index 100C
h
and 100D
h
shall indicate the congured guard time respectively the life time
factor. The life time factor multiplied with the guard time gives the life time for the life guarding protocol.
Object Description
Index Name Object Type Data Type
100C
h
Guard Time Variable UNSIGNED16
Table 19: Object Description (100C
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 rw no UNSIGNED16 0
Table 20: Entry Description (100C
h
)
3.1.8 Object 100D
h
: Life Time Factor
The life time factor multiplied with the guard time gives the life time for the life guarding protocol.
Object Description
Index Name Object Type Data Type
100D
h
Life Time Factor Variable UNSIGNED8
Table 21: Object Description (100D
h
)
