PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
15 / 86
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 rw no UNSIGNED32 80
h
Table 12: Entry Description (1005
h
)
3.1.4 Object 1008
h
: Manufacturer Device Name
This object contains the name of the device as given by the manufacturer.
Object Description
Index Name Object Type Data Type
1008
h
Manufacturer Device Name Variable Visible String
Table 13: Object Description (1008
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 ro no — PD42-x-1670
Table 14: Entry Description (1008
h
)
3.1.5 Object 1009
h
: Manufacturer Hardware Version
This object contains the hardware version description.
Object Description
Index Name Object Type Data Type
1009
h
Manufacturer Hardware Version Variable Visible String
Table 15: Object Description (1009
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 ro no — Depends on device, e.g. 1.0.
Table 16: Entry Description (1009
h
)
3.1.6 Object 100A
h
: Manufacturer Software Version
This object contains the software version description.
