PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
13 / 86
The communication profile area at indices 1000
h
through 1FFF
h
contains the communication specific
parameters for the CAN network. These entries are common to all devices.
The manufacturer segment at indices 2000
h
through 5FFF
h
contains manufacturer specific objects. These
objects control the special features of the Trinamic PD42-x-1670 motion control device.
The standardized device profile area at indices 6000
h
through 9FFF
h
contains all data objects common to a
class of devices that can be read or written via the network. They describe the device parameters and the
device functionality of the device profile.
3 Communication area
The communication area contains all objects that define the communication parameters of the CANopen
device according to the DS301 standard.
3.1 Detailed object specifications
3.1.1 Object 1000
h
: Device Type
This object contains information about the device type. The object 1000
h
describes the type of device
and its functionality. It is composed of a 16-bit field which describes the device profile that is used and a
second 16-bit field which provides additional information about optional functionality of the device.
Object Description
Index Name Object Type Data Type
1000
h
Device type Variable UNSIGNED32
Table 5: Object Description (1000
h
)
Entry Description
Sub-index Access PDO Mapping Value Range Default Value
0 ro no UNSIGNED32 00420192
h
Table 6: Entry Description (1000
h
)
3.1.2 Object 1001
h
: Error Register
This object contains error information. The CANopen device maps internal errors into object 1001
h
. It is
part of an emergency object.
Object Description
Index Name Object Type Data Type
1001
h
Error register Variable UNSIGNED8
Table 7: Object Description (1001
h
)
©2018 TRINAMIC Motion Control GmbH & Co. KG, Hamburg, Germany
Terms of delivery and rights to technical change reserved.
Download newest version at www.trinamic.com
