PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
37 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
0 Node ID no 1 127 1 RW
Table 88: Entry Description (2705
h
)
4.1.19 Object 2706
h
: User Variables
Object Description
Index Name Object Type Data Type
2709
h
User Variables Variable Record
Table 89: Object Description (2706
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 Address no 0 255 0 RW
2 Data no -2147483648 2147483647 0 RW
3 Store no 0 4294967295 305419896 RW
Table 90: Entry Description (2706
h
)
4.1.20 Object 270E
h
: Analog Inputs
Object Description
Index Name Object Type Data Type
270E
h
Analog Inputs Variable Record
Table 91: Object Description (270E
h
)
