PD42-x-1670 CANopen Firmware Manual • Firmware Version V2.0 | Document Revision V1.0 • 2018-Nov-07
31 / 86
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ActualCurrent no -2147483648 2147483647 0 [mA] (peak) R
2 TargetCurrent no -7400 7400 0 [mA] (peak) R
3 RampTargetCurrent no -7400 7400 0 [mA] (peak) R
4 P_Parameter no 0 65535 0 RW
5 I_Parameter no 0 65535 0 RW
6 PI_Torque_Error no -2147483648 2147483647 0 [mA] R
7 PI_Torque_Error_Sum no -2147483648 2147483647 0 R
8 PI_Flux_Error no -2147483648 2147483647 0 [mA] R
9 PI_Flux_Error_Sum no -2147483648 2147483647 0 R
Table 64: Entry Description (2030
h
)
4.1.8 Object 2040
h
: Velocity Mode Settings
Object Description
Index Name Object Type Data Type
2040
h
Velocity Mode Settings Variable Record
Table 65: Object Description (2040
h
)
Entry Description
Sub- PDO
index Name Mapping Min Max Default Unit Access
1 ActualVelocity no -2147483648 2147483647 0 [rpm] R
2 TargetVelocity no -200000 200000 0 [rpm] R
3 RampTargetVelocity no -2147483648 2147483647 0 [rpm] R
4 MotorHaltedVelocity no 0 200000 5 [rpm] RW
5 P_Parameter no 0 65535 0 RW
6 I_Parameter no 0 65535 0 RW
7 PI_Velocity_Error no -2147483648 2147483647 0 [rpm] R
8 PI_Velocity_Error_Sum no -2147483648 2147483647 0 R
Table 66: Entry Description (2040
h
)
