User's Manual

DRAFT TrimTrac Locator Technical Manual 36
QUERY_CONFIG
This QUERY_CONFIG message is used by the server application to request the
TrimTrac locator send its TrimTrac Application, GPS or Communication
parameters in the appropriate RESP_APP_CONFIG, RESP_PROV_CONFIG or
RESP_GPS_CONFIG message.
>QTKA;PW=PPPPPPPP;ID=YYYYYYYY;*ZZ<
A TrimTrac Configuration Set: ‘G’ = GPS Parameters
‘A’ = Application Parameters
‘V’ = Provisioning Parameters
PPPPPPPP Security Password. Always 8 digits. Default 00000000
YYYYYYYY Unit ID. Unique unit identifier. Always 8 digits. Default
00000000
ZZ Checksum.
Table 17, QUERY_CONFIG Message
RESP_APP_CONFIG
This is the response message to the SET_APP_CONFIG and QUERY_CONFIG
messages containing the Application Parameter values.
>RTKABBBBBBCCCCCCDDDDDDEEEEEEFFFFFFGGGTTHIJKLLLLMMMMMMNP
P;ID=YYYYYYYY;*ZZ<
A TrimTrac Configuration Set: ‘A’ = Application Parameters
BBBBBB Idle Timeout. In seconds (10 – 999999)
CCCCCC Fix Timeout. In seconds (10 – 999999)
DDDDDD Comm Timeout. In seconds (10 – 999999)
EEEEEE Sleep Time. In seconds (10 – 999999)
FFFFFF Query Time. In seconds (10 – 999999)
GGG Almanac Timeout. In hours (10 – 999)
TT Motion Timeout. In seconds (5 – 99)
H Motion Report Flag. 0:None; 1:Report first motion before GPS fix
I Report Delay Flag. 0:Log & Transmit messages; 1:Log messages
J Diagnostics Mode. 0: None; 1: LED
K Communications Mode. 0: SMS; 1: Future
LLLL Battery Change Week.
MMMMMM Battery Change Seconds into Week.
N.PP Firmware version number.
YYYYYYYY Unit ID. Unique unit identifier. Always 8 digits
ZZ Checksum.
Table 18, RESP_APP_CONFIG Message
RESP_PROV_CONFIG
This is the response message to the SET_PROV_CONFIG and
QUERY_CONFIG message containing the provisioning information.
