REPORT_POS and STATUS_MSG
These two messages are the most common and contain status information such as
ReportType, WakeupType, Old/New Fix Indicator, Battery Condition, and
Position Data. The difference between the REPORT_POS and STATUS_MSG is
that the REPORT_POS message contains position information. Whereas, the
STATUS_MSG does not contain any position related information due to, for
instance, the TrimTrac locator not being able to obtain a GPS fix.
>RTKABBBBCDDDEFFFFGGGGGGST[HHHIIIIIIIJJJJKKKKKKKLLLLLL
MMMNNN];ID=YYYYYYYY;*ZZ<
A TrimTrac Report Type: ‘P’ = Position Report
‘S’ = Status Report
BBBB Protocol Sequence Number: 16-bit hex value, increments by 1
each report message
C Wakeup Event: ‘0’ = RTC Timeout
‘1’ = Motion Detected
DDD Battery Level: Measured in percent of maximum. Range 0% to
100%.
E Battery Changed Flag.
FFFF GPS Week Number
GGGGGG GPS Seconds into Week
S GPS Error Status Code: ‘0’ = 3D GPS Fix.
‘1’ = 2D GPS Fix.
‘2’ – ‘5’ = Fix Timeout, 0 – 3 SVs.
‘6’ = GPS Error.
‘7’ = No Fix Attempted, Status
T GSM Error Status Code: ‘0’ = Network Available.
‘1’ = Message Logged
(Report Delay Flag set).
‘2’ = Network Timeout.
‘3’ = SIM Error / No SIM.
‘4’ = SIM PIN Error.
‘5’ = Pre-TX log (Low battery).
YYYYYYYY Unit ID. Unique unit identifier. Always 8 digits
ZZ Checksum.
Optional
HHH.IIII
III
Latitude in WGS-84 coordinates (positive = north). Units of
degrees.
JJJJ.KKK
KKKK
Longitude in WGS-84 coordinates (positive = east). Units of
degrees.
LLLLLL Altitude above MSL. Units of feet.
MMM Horizontal Speed. Units of MPH.
NNN Heading based on True North, increasing easterly. Units of
degrees.
Table 13, REPORT_POS and STATUS_MSG Messages
