Trilogy Touch Technology 17” Chassis Touch Screen Monitor T3-HB17A1
Table of Contents GETTING STARTED 1 Introduction Features Unpacking and Checking of the Package Contents Accessories Included System Requirements Mounting Using Input INSTALLING THE MONITOR 3 Connecting the Monitor OPERATING THE MONITOR 4 Adjusting the Viewing Angle Operating Procedure Additional information about the On-Screen-Display Menu Table FOR YOUR SAFETY 8 SPECIAL NOTES ON LCD MONITORS 9 Cleaning Power Management Supported Timing Troubleshooting Procedures CONFORMITY AND COMPLIANCE 1
Copyright © 2004, Trilogy Touch Technology, Inc. All rights reserved The information contained in the document is subject to change without notice. Nor does the contained information constitute a warranty, either expressed or implied or as an obligation by Trilogy Touch Technology. Trilogy Touch Technology shall not be liable for the accuracy of the information, fitness for purpose or direct or indirect consequential damages.
GETTING STARTED WARNING: Do not operate the LCD Monitor with an unknown utility power voltage source. Usage of incorrect voltage may cause malfunctions and could cause fire or electric shock. INTRODUCTION Thank your for your selection of this Trilogy Touch Technology product. Bright and sharp images of text and graphics are what you will find with your LCD Monitor.
SYSTEM REQUIREMENTS The following are basic requirements for using the Monitor. Please check the specifications and Supported Video Timing section of this Users Guide for specifics. • This monitor requires connection to a personal computer. Both industry standard architecture and Macintosh hardware is supported. • Various Operating System versions are supported for input operation. Please check the product features and specifications to insure that the OS you intend to use is supported.
INSTALLING THE MONITOR • DO NOT install the monitor in areas where sudden temperature changes may occur, or in humid, dusty, or smoky environments as it may cause fire, electric shock or damage.
OPERATING THE MONITOR Users can adjust the picture to the desired brightness and sharpness by following these instructions. The adjustment buttons utilize a security feature that required the use of a paper clip or pin to activate each selection. This is accomplished through pinholes in each button except the power on/off.
HOW TO USE THE OSD (ON SCREEN DISPLAY) The OSD function allows the user to easily adjust the display to the desired requirements. The OSD menu includes a main menu and sub-menus. OPERATING PROCEDURE Use the buttons on the right side control panel to adjust the OSD (see Operating the Monitor). Color Temp. Selection Language Volume Adjustment Settings Image Adjustment Input Source Selection Current Audio Status Color Temp.
made in the “Settings” submenu. • Any changes made are automatically saved in the Monitor memory when the OSD disappears. Turning off the power should be avoided while using the OSD, as this may not allow changes to be saved. • Adjustments for clock, phase and positions are saved for each signal timing or screen resolution. Except for these adjustments, all other adjustments have only one setting that applies to all signal timing.
MENU TABLE Primary Secondary Directory Directory Description Image Brightness Adjust the brightness of the screen. Contrast Adjust the contrast of the image. Clock Adjust the clock pulse of the image. Phase Adjust the focus of the image. H. Position Move the image left and right on the screen. V. Position Move the image up and down on the screen. Sharpness Adjust the picture sharpness of lower resolutions. Audio Color Volume Adjust the volume of the audio.
FOR YOUR SAFETY WARNING • ALWAYS OPERATE UNDER KNOWN POWER SUPPLY Usage of incorrect voltage will cause malfunctions and may cause fire or electric shock. • PROTECT and CORRECTLY USE THE SIGNAL CABLES Do not pull or bend the power cable and signal cable or place the monitor or any heavy objects on the cables. If the cables are damaged, they may cause fire or electric shock.
SPECIAL NOTES ON LCD MONITORS The following are normal with LCD Monitors and do not indicate a problem. • When the LCD Monitor is first powered on, the picture may not fit in the display area. This is because of the type of computer graphics system that is used. In such case, adjust the picture position to a desired image (See Operating the Monitor). • The screen may flicker during initial use. Turn off the power and then turn it on again the flickering should disappear.
POWER MANAGEMENT This LCD Monitor complies with the VESA DPMS (version 1.0p) power management specification. DPMS provides four types of power saving modes by detecting the horizontal or vertical sync signal. As well, the computer graphic card also needs to be DPMS compliant to utilize these modes.
PROBLEM CHECK TO SEE: No Display. Is the power cord is firmly plugged in the socket. a) Power indicator does not light up. Is the power switch is turned on. Is the AC outlet is OK. Please check using another piece of equipment. Is a blank screen saver is active, use the keyboard or mouse to activate. Increasing the CONTRAST and/or BRIGHTNESS to b) Power indicator is green. display an image. Is the computer is ON. Is the signal cable is properly connected at both ends.
CONFORMITY AND COMPLIANCE FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.
PRODUCT SERVICE AND SUPPORT Should this product fail or require service, please contact your Dealer or Distributor for service or support. The Dealer or Distributor may have specific programs for support of this product, or may provide specific services outside the scope of the manufacturer’s original warranty. Should support from the manufacturer become necessary, please use the contact information listed below. Be prepared to provide the following information, which is required.
Warranty (United States) Trilogy Touch Technology TOUCH MONITOR LIMITED WARRANTY A. Limited Warranty Trilogy Touch Technology, Inc. (“Trilogy”) warrants the TFT-LCD touch monitor(s) (“the Monitor”) or (“product”) you have purchased from Trilogy or from a Trilogy Authorized Reseller, to be free from defects in materials and workmanship under normal use for a period of three (3) years. The warranty period begins on the date of purchase.
C. Trilogy Service Policies Product service is subject to the following terms and conditions. Customers may contact their dealer or distributor for their respective service entitlement and policies. 1. 2. 3. 4. 5. 6. 7. 8. Service is available for Monitors purchased and located in the continental United States, Canada, Alaska, Hawaii and Puerto Rico. Shipments to customers cannot be made to PO Boxes.
17” Chassis Monitor T3-HB17A1 Dimension Drawing Trilogy Touch Technology Dimensions in mm
