132993190.qxd 9/10/02 8:56 AM Pagina 2 (Nero/Process Black pellicola) Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.
132993190.qxd 9/10/02 8:56 AM Pagina 3 (Nero/Process Black pellicola) Contents For the User Important Safety Information Your New Washer-Dryer Description of the Appliance 2 The Control Panel Operating sequence 6 Detergent dispenser drawer Washing 4.
132993190.qxd 9/10/02 8:56 AM Pagina 4 (Nero/Process Black pellicola) Your New Washer-Dryer Your new washer-dryer meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. It is gentle with your laundry, simple to use and easy to care for. ● ● ● ● The special wool programme with its new delicate wash system treats your woollens with extreme care. The anti-unbalance device ensures that the machine remains stable when spinning.
132993190.
132993190.
132993190.qxd 9/10/02 8:57 AM Pagina 7 (Nero/Process Black pellicola) Operating Sequence 3. Measure out the fabric softener Before the first wash, we recommend that you run a cotton cycle at 60°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the main wash compartment of the dispenser drawer and start the machine.
132993190.qxd 9/10/02 8:57 AM Pagina 8 (Nero/Process Black pellicola) 6. At the end of the programme The machine stops automatically. The door is controlled by a safety device which releases 2 minutes after the end of the programme. Switch the machine off by depressing the ON/OFF button again. The mains-on light goes out. Remove the laundry. When the programme has finished you are advised to unplug the appliance and turn off the water tap.
132993190.qxd 9/10/02 8:57 AM Pagina 9 (Nero/Process Black pellicola) WASHING 2 KG OF MIXED FABRICS AT 50°C Suppose you have 2 kg of Mixed fabrics to wash. They are rather delicate fabrics and should not be washed at a high temperature. 4. Select the programme Turn the programme selector dial clockwise to the programme 7. 1. Load the laundry 7 Open the door by pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door.
132993190.qxd 9/10/02 8:57 AM Pagina 10 (Nero/Process Black pellicola) DRYING 2.25 KG OF COTTON You have for example just machine-washed and spun at 1000 rpm 4.5 kg (10 lb) of laundry. They are cotton fabrics of medium weight which you want to iron as soon as they are dry. Switch off the machine. Then remove the laundry from the appliance and divide the items to obtain two loads of approx. 2.25 kg (5 lb) each. 4.
132993190.qxd 9/10/02 8:57 AM Pagina 11 (Nero/Process Black pellicola) AUTODRYING 1 KG OF MIXED FABRICS You intend to wash and dry automatically 1 kg (2.2 lb) of mixed fabrics which do not need ironing. Proceed as follows: 1. Load the laundry. 2. Add the washing powder and fabric softener. 6. At the end of the programme The machine stops automatically and the drying light goes out. The door is controlled by a safety device which releases 2 minutes after the end of the programme.
132993190.qxd 9/10/02 8:57 AM Pagina 12 (Nero/Process Black pellicola) Washing and Drying Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance.
2993190.qxd 9/10/02 8:57 AM Pagina 13 (Nero/Process Black pellicola) Which detergent?.... And in which form? To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines.
132993190.qxd 9/10/02 8:57 AM Pagina 14 (Nero/Process Black pellicola) Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine.
132993190.qxd 9/10/02 8:57 AM Pagina 15 (Nero/Process Black pellicola) Washing Programmes Programmes for cottons and linens Wash programme/ Washing symbol Degree of soil and type of laundry Programme dial position Possible options Max. load 1 Prewash at 40 °C Wash at 95°C 3 rinses Long spin HALF LOAD 4.5 kg WHITES White cotton, for example normally soiled work garments, sheets, household linen, underwear, towels. 2 Wash at 95 °C 3 rinses Long spin HALF LOAD 4.
132993190.qxd 9/10/02 8:57 AM Pagina 16 (Nero/Process Black pellicola) Washing Programmes Programmes for synthetics, mixed fabrics, wool and delicates Degree of soil and type of laundry Possible options Max. load Programme dial position Description MIXED FABRICS Synthetic or mixed fabrics, underwear, coloured garments, non-shrink shirts, blouses.
132993190.qxd 9/10/02 8:57 AM Pagina 17 (Nero/Process Black pellicola) Drying Programmes Degree of drying Type of fabric Cotton and linen (towels, T-shirts, bathrobes) Programme 6 Store dry (*) Suitable for items to put away Synthetics and mixed without ironing fabrics (jumpers, blouses, underwear, household linen) Programme 12 Iron dry Suitable for ironing Cotton and linen (sheets, tablecloths, shirts, etc.) Programme 6 Max.
132993190.qxd 9/10/02 8:57 AM Pagina 18 (Nero/Process Black pellicola) Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. Do this separately from any laundry washing, and according to the softening powder manufacturer's instructions.
132993190.qxd 9/10/02 8:57 AM Pagina 19 (Nero/Process Black pellicola) The dangers of freezing Unscrew and remove the filter. Clean carefully under a fast running tap. P0133 If the machine is exposed to temperatures below 0°C, certain precautions should be taken. ● Turn off the water tap. ● Unscrew the inlet hose. ● Unhook the drain hose from the rear support and position the end of this hose and that of the inlet hose in a bowl. Run the draining programme. ● Disconnect the appliance.
132993190.qxd 9/10/02 8:57 AM Pagina 20 (Nero/Process Black pellicola) Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
132993190.qxd 9/10/02 8:57 AM Pagina 21 (Nero/Process Black pellicola) Symptom Possible causes The door will not open ● ● ● The programme is still running. The door lock has not yet released. Water in the tub: the door cannot be opened if water is present in the tub. Spinning starts late or the machine does not spin ● The electronic unbalance detection device has cut in because the laundry is not evenly distributed in the drum. The laundry is redistributed by reverse rotation of the drum.
132993190.
132993190.qxd 9/10/02 8:57 AM Pagina 23 (Nero/Process Black pellicola) Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
132993190.qxd 9/10/02 8:57 AM Pagina 24 (Nero/Process Black pellicola) Fill all the holes with the plastic plugs supplied with the instruction booklet. Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the two rear bottom screws. Slide out the two plastic pins.
132993190.qxd 9/10/02 8:57 AM Pagina 25 (Nero/Process Black pellicola) Water drainage Connect the hose to a tap with a 3/4” thread. Do not use previously used hoses for water connection. This appliance is designed to be permanently plumbed into your home's water supply and drainage system. The appliance drain hose should hook into a standpipe, the hook in the drain hose is formed using the plastic “U-Piece” supplied.
132993190.qxd 9/10/02 8:57 AM Pagina 26 (Nero/Process Black pellicola) Special conditions If you intend the drain hose to empty into a sink, make sure that the sink is empty and the plug hole is not blocked. Use the plastic “U-Piece” supplied. If the floor is carpeted or covered with crumbly or soft material, insert a rigid support base under the feet to prevent noise, vibration or displacement. The base should protrude a few centimetres beyond the edges of the machine.
132993190.qxd 9/10/02 8:57 AM Pagina 27 (Nero/Process Black pellicola) Electrical connection The wire coloured blue must be connected to the terminal marked «N» or coloured black. The wire coloured brown must be connected to the terminal marked «L» or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cord clamp must be secure over the outer sheath.
