CONTENTS Wakings Page 3 Installation Page 45 Electrical Connections Page 8 Use Page 7 Control Panel Pas 7 Controllers Page 7 Drying Times. Page 8 Drying 45kg (cottonseed Page g Nondrying (4.5 ) of synthetics Page 9 Nondrying Page 10 Maintenance. Page 11 External Cleaning Page 11 Housecleaning Page 11 Noninterchangeable Page 11 Servicing Page 11 Guarantee Conditions Page 12 Vicegerents Page 1318 TECHNICAL SPECIFICATIONS DIMENSIONS: Height: 85 cm Width: 60 cm Darth: 57 cm Weight: 20.
WARNINGS 1T IS MOST IMPORTANT THAT THIS INSTRUCTION BOOK SHOULD BE RETAINED WITH THE APPLIANCE FOR FUTURE REFERENCE. SHOULD THE APPLIANCE BE SOLD OR TRANSFERRED TO ANOTHER OWNER, OR SHOULD YOU MOVE HOUSE AND LEAVE THE APPLIANCE, ALWAYS ENSURE THAT THE BOOK IS LEFT WITH THE APPLIANCE IN ORDER THAT THE NEW OWNER CAN GET TO KNOW THE FUNCTIONING OF THE APPLIANCE AND THE RELEVANT WARNINGS. THESE WARNINGS ARE PROVIDED IN THE INTEREST OF SAFETY.
INSTALLATION Positioning The appliance may be placed in any room, provided the {hollowing precautions are taken. The appliance expels hot, very moist air. The rest of the house must be able to easily absorb this moisture. Normally, absorption is only possible in houses where there is very lifebelt humidity. Otherwise, the room must have ventilation towards the outside; generally, an open door or window is enough.
Condensation discharge at the front vso Remove the small cover and introduce the vent hose with the collar info the vent outlet. The tongue on the collar should correspond with the slot on the vent hole. Then push firmly to ensure secures fit. i 1f you use the front or side vent outlet, the cover you [ have removed should be | 2 placed at the back. 2t Note The cover on the front vent outlet will only fit the rear vent outlet.
Electrical Connections WARNING: THIS APPLIANCE MUST BE EARTHED, The manufacturer declines any ability should this safety measure not be observed. If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off, and the appropriate plug fitted. Remove the fuse from the cut off plug. The cut off pig should then be disposed of to prevent the hazard of electric shocks in case it should be plugged into a 13 Amp socket in another part of your home.
USE Control Panel TRINITY BENDIX REVERSE ACTION ||CHEGKFILTER MANSON MALE TUMBLE DRYER HEAT HEAT bear ST r wear CHECK FILTER LIGHT 5 DRYING TIME SELECTOR This light comes on when you open the door at the end of the cycles or during drying 1o check the clothes to remind you that the filter should be cleaned at the end of the programmer. When you close the door the light goes off.
DRYING TIMES Cotton and Linen Selector dial: up to 120 minutes (FULL HEAT section) Degree of drying required Degree of spin given Quantity Selector dial setting and fables on articles 101b (4.5 kg) 80-95 mind 800 rpm 551b (2.5 kg) §5-65 Ming Store dry &3] 101b (4.5 kg) 70-80 mind 1000-1200 imp 551b (2.5 kg) 45-55 mind 101b (4.5 kg) 60-75 mind 800 rpm 5.5 (25kg) 45-55 mind iron dry E 101b (4.5 kg) 55-65 mind 1000-1200 rpm 5.51b (2.
DRYING COTTON You have for example just machine-washed and spun at 1200 rpm laundry. They are cotton fabrics of medium weight which you want to iron as soon as they are dried. 1. Load the laundry Open the door by pulling t outward, Load the items one at a time, shaking them out loosely and close the door, Please check the foundry does not get caught between the door and filter. 2. Depress the required button(s). 3.
HINTS ON DRYING = Do not overfond the appliance. Here is a list of the average of the more common laundry items according to an approximate basis. Sheet 7001010009 Pillowcase 100th 2009 Tablecloth 40010 500¢g Table napkin 50th 100¢g Kitchen towel 70th 120g Linen hand tows 100th 150g Hand towel 150th 250¢g Cathy toque! 70010 1000 g Bathrobe 100010 1500 g Shirt 20010 300g ron 15010 200 However, the best and most economical load is the maximum indicated for the different types of fabric.
MAINTENANCE Important You must disconnect the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External Cleaning Use only soap and water and then dry thoroughly. From time to time, apply a little wax furniture cream with a soft cloth. Important: do not use mediated spirit, diluent or similar products. Cleaning The Door Clean periodically the interior part of the door to remove any fluff. Accurate cleaning ensures correct drying.
TRINITY BENDIX GUARANTEE CONDITIONS We, Trinity Bendix, undertake that if within 12 months of the date of the purchase this Trinity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF ANY CHARGE for labor, materials or carriage on condition that: ® The appliance has been installed correctly and used only on the electricity supply stated on the rating plate.
