OPERATING & INSTALLATION INSTRUCTIONS FREEZER TFT 12 JA 200380215 I/T/9. (05.
This instruction book contains safety precautions, information on use and helpful hints and tips. To ensure you use this appliance effectively and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference.
IMPOR TANT S AFET Y INS TR UCTIONS These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department. Do not place carbonated or fizzy drinks in the Prior to installation freezer. Check the appliance for transport damage.
C ONTENT S Instructions for the User Instructions for the Installer Guide to use the instruction book 2 Technical data 12 Important Safety Information 3 Instructions for the User General Information Description of the Appliance 5 5 5 Installing the Appliance Transportation, Unpacking Location Ventilation Requirements Levelling 12 12 12 13 13 Indicator Lights Fast Freeze Facility Basket Storage Freezer Tray 6 6 6 6 Door Reversal 14 Electrical Connection 15 Using the Appliance Before Use To
INS TR UCTIONS F OR THE USER General information This appliance is designed for the freezing and storage of frozen food in a domestic home. To ensure correct operation, the appliance should be located where the ambient temperature is between 16-32 °C. Description of the Appliance 1. Freezing tray (with 4 ice trays) 6. Defrost water outlet 2. Freezing compartment 7. Adjustable feet 3. Storing compartments (wire baskets) 8. Door gasket 4. Rating Plate 9. Thermostat 5. Control Panel 10.
Indicator Lights The indicator lights are situated in the control panel. A.)Green Indicator Light When the appliance is switched on at the mains the green indicator light will glow and continue to glow until the appliance is switched off at the mains. B.)Red Indicator Light A few hours after starting up this will go out to show that the correct temperature has been reached for the setting chosen and will stay out to indicate that everything is in order.
Using the Appliance Before Use Remove all packaging and securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0,5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Do not use detergents, abrasive powders, highly perfumed cleaning products, wax polishes or products containing alcohol. ) To Start the Appliance 1. Allow the appliance to stand for 2 hrs after installation. 2. Plug in the appliance and switch on at the mains supply.
3. Then push the fast freezer switch again (the yellow light will go out and the switch turns to its original position). 4. The freezing tray is suitable for freezing smaller fruits (raspberry, strawberry, currant, etc.). Fruits should be put on the tray in thin layers without packaging. After freezing they can be packed and sorted out then placed into the storing compartments. If the 'fast freeze' switch is accidentally left on, the freezer will not be damaged, but energy will be wasted.
Energy Saving Advice Do not install the appliance close to sources of heat, such as a boiler or radiator. Locate the appliance in a cool well ventilated room and make sure that the air openings of the appliance are not obstructed. Avoid unnecessary frosting in the cabinet by packing all foodstuffs into airtight packages before placing them in the freezer. Food which is to be frozen (when cool) should be placed in the fridge before being transferred to the freezer.
) To carry out complete defrosting: 1. Disconnect the appliance from the electrical supply. If the plug is inaccessible turn the thermostat control knob to „0“. 2. Remove any stored food, wrap in several layers of newspaper and store in a cool place. 3. Leave the door open. 4. Carefully draw the plastic drain spout out of the lower part of the appliance according to the direction of the arrow and place a tray of a suitable size in the position shown. 5.
Ser vice and Spar e P ar ts For Customer Service in Ireland please contact us at the address below: Electrolux Group (Irl) Ltd Long Mile Road Dublin 12 Republic of Ireland Tel.: +353 (0) 1 4090753 Email: service.eid@electrolux.ie When you contact the Service Centre you will need to give the following details: 1. Your name, address and post code 2. Your telephone number 3. Clear and concise details of the fault 4. The model and serial number of the appliance (found on the rating plate) 5.
Ins tr uctions f or the Ins t aller Technical data Model Gross capacity (l) Net capacity (l) Width (mm) Height (mm) Depth (mm) Energy consumption (kWh/day) (kWh/year) Energy class, according to EU Standards Freezing capacity (kg/24h) Rising time (h) Rated power (W) Weight (kg) TFT 12 JA 117 100 550 850 600 0,77 281 B 16 17 90 39 Installing the appliance Location Transportation, unpacking The appliance should be positioned in a well ventilated, dry room.
Ventilation Requirements The appliance must have adequate ventilation to ensure correct operation. Diagram shows the ventilation requirements when installed: A* Under a worktop, or cupboard. * The clearance space of 10 cm above the appliance may be reduced to 5 cm providing a clearance space 2.5 cm is left on either side of the appliance. B When freestanding Levelling The appliance must be level. Level the appliance by adjusting the two adjustable feet (1) at the front of the appliance.
Fit the door in place on the hinge pin. Refit the bottom hinge plate assembly on the opposite side, taking care that the edge of the door is parallel with the side of the cabinet. Slot the hinge pin into the hole in the hinge plate and relocate the hinge assembly to the opposite location and refit using the retaining screws. To reverse the handle proceed as follows: Remove screw covers (if fitted) and handle retaining screws. Remove blanking plugs on the opposite side using a punch.
Electrical Connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. The appliance is supplied with a 13 amp plug fitted.
