OPERATING & INSTALLATION INSTRUCTIONS WASHING MACHINE TB1000 W 35.292.
.
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These informations has been provided in the interest of safety.
i Your New Washing Machine Your new washing machine, meets all modern needs for effective treatment of laundry with low water, energy and detergent consumption. ■ ■ ■ In the interest of the environment Automatic cooling of the wash water to 60°C before draining, with the 90°C programme. This reduces thermal shock to fabrics, helping to prevent any creasing. The special wool programme with its new delicate wash system treats your woollens with extreme gentleness.
Contents For the User For the Installer Important Safety Information Your New Washing Machine Description of the Appliance The Control Panel Operating sequence Installation Instructions Technical Specifications 3 4 Unpacking Positioning Water inlet Water drainage Levelling Special conditions In the interest of the environment Electrical connections Permanent connection Tricity Bendix Service Force Addresses 6 7 8-11 8 8 8 8 8 9 9 10 10 10 10 10 11 11 11 Washing 4,5 kg of white cotton at 90 °C Load th
Description of the Appliance Detergent dispenser drawer “Mains-on” light “Options” buttons Programme guide Program selector dial & ON/OFF switch Door opening handle Filter Adjustable feet 9 8 1 2 3 4 5 6 7 8 Detergent dispenser drawer Prewash Main Wash Fabric softener AL035 6
The Control Panel 1 Detergent dispenser drawer 5 Programme Guide 2 Mains-on light 6 Programme Selector This light illuminates when the appliance is operating. To select the required program turn the control clockwise until the marker on the top coincides with the number of the required programme (reference mark on the control panel). If you pass the required number NEVER TURN THE CONTROL ANTICLOCKWISE just continue clockwise until the required number is reached again.
Operating Sequence Before your first wash, we recommend that you run a cotton cycle at 60°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine. WASHING 4.5 KG OF WHITE COTTON AT 90°C Suppose you have 4.5 kg of heavily soiled laundry to wash. It is white cotton and is suitable for high temperature washing 1. Load the laundry Open the door.
5. Select the required programme Turn the programme selector dial CLOCKWISE to the required programme. 1 P0215 6. Start the machine Before starting up the machine check that: ■ the appliance is plugged in ■ the water supply taps are turned on ■ the door and the detergent dispenser drawer are closed. Pull the programme selector dial outwards The operating pilot light will illuminate and the machine will start operating 1 P0216 7.
WASHING 2 KG OF MIXED FABRICS AT 50 °C Suppose you have 2 kg of MIXED FABRICS to wash. They are rather delicate fabrics and should not be washed at a high temperature. 1. Load the laundry Open the door. Place the laundry in the drum, one item at a time, shaking out as much as possible. Close the door. P0004 2. Measure out the detergent Pull out the dispenser drawer until it stops.
5. Select the required programme Turn the programme selector dial CLOCKWISE to the required programme 7 P0215 6. Start the machine Before starting up the machine check that: ■ the appliance is plugged in ■ the water supply taps are turned on ■ the door and the detergent dispenser drawer are closed. Pull the programme selector dial outwards The mains-on light will illuminate and the machine will start operating 7 P0216 7.
i Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance.
Delicate Items Which detergent to use?.... When washing delicates such as woollens, you should use a product which is specially designed to care for fine fabrics. Dreft Automatic is suitable for woollens and other delicates. To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines.
And in which form? Bounce conditioning sheets for use in a tumble dryer. We recommend the conditioning sheets are pinned (using a safety pin) to an article of laundry and placed in the tumble dryer. Not only are there different types of detergent, but they are also available in different forms. Whether you choose a powder or liquid in traditional or compact form is down to personal choice. Traditional Powders Pour the powder directly into the dispenser drawer.
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. WASHING SYMBOL WASH ACTION 95 Normal (Maximum) White Cotton or Linen without Special Finishes 60 Normal (Maximum) Cotton, Linen or Viscose without Special Finishes Colour fast at 60°C.
Washing Programmes Programmes for cotton and linen Wash programme Degree of soil and type Programme dial of laundry position White cotton, for example heavy soiled sheets, Whites+Prewash garments, household linen, underwear, towels. Description Possible options Max. load Prewash at 40 ˚C Wash at 90˚C 4 rinses Long spin at 1000 rpm 4.5 kg 2 Wash at 90˚C 4 rinses Long spin at 1000 rpm 4.5 kg 3 (*) Wash at 60˚C 4 rinses Long spin at 1000 rpm 4.
Washing Programmes Programmes for synthetics, delicates and wool Wash programme Degree of soil and type of laundry Programme dial position Description Possible options Max. load Mixed fabrics Synthetic or mixed fabrics, underwear, coloured garments, nonshrink shirts, blouses. Synthetics Synthetic or mixed fabrics, underwear, coloured garments, nonshrink shirts, blouses.
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply Descaling The water we normally use contains lime. It is a good idea to periodically run a high temperature wash with detergent or use a descaler in the machine. Do this separately from any laundry washing, and according to the manufacturer's instructions. This will help to prevent the formation of lime deposits. After each wash Leave the door open for a while.
Cleaning the filter The water drain filter A clean filter is important for the correct functioning of the machine, and should therefore be cleaned after every washing programme. Open the filter door and place a container underneath to catch any spillage. If the filter is blocked and the machine is unable to drain you will need to drain the water manually from the machine at this stage. To do this, unhook the drain hose from the standpipe or sink and hold the end of the hose over a bowl on the floor.
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your Tricity Bendix Service Force Centre, please carry out the checks listed below. Important: If you call out an engineer to a fault if listed below or to repair a fault caused by incorrect use or installation a charge will be made even if the appliance is in guarantee.
Symptom Possible causes The door will not open ■ ■ ■ The programme is still running. The door lock has not yet released The water level in the drum is too high or the machine is heating. Spinning starts late or the machine does not spin ■ The electronic unbalance detection device has cut in because the laundry is not evenly distributed in the drum. The laundry is redistributed by reverse rotation of the drum.
Peace of Mind for Twelve Months Tricity Bendix standard guarantee conditions Exclusions This guarantee does not cover: ■ Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or removable parts of glass or plastic. ■ Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the United Kingdom.
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person.
Unpacking All transit bolts and packing must be removed before using the appliance You are advised to keep all the packaging for re-use in case the appliance has to be transported again. ■ Unscrew and remove the three rear transit bolts (using a spanner). P0287 ■ Lay the machine gently on its back, making sure that the hoses are not squashed. We suggest a polystyrene angle bracket from the packing is placed on the floor before tilting it back to avoid the hoses being squashed.
Positioning Your new Tricity Bendix washing machine has been designed to be permanently plumbed in to your home’s water supply and drainage system. However, if this is not possible, it may be connected to suitable existing taps, with the drain hose discharging into the sink. The appliance has two inlet hoses, hot and cold, with female 3/4” BSP thread connectors.
Water drainage This appliance is designed to be permanently plumbed into your home's water supply and drainage system. Max. 90 cm.(35.4") The appliance drain hose should hook (use the plastic “U-piece” supplied) into a standpipe with an internal diameter of approximately 38mm (see diagram) thus ensuring there is an air break between the drain hose and standpipe. P1039 Min. 30 cm.(12") When discharging into a standpipe ensure that the top of the curve in the hose end is no more than 90cm (35.
Levelling Level the washing machine by loosening or tightening the feet. Once in the right position fix the feet by pushing the nuts against the base of the case. Accurate levelling prevents vibration, noise and displacement of the machine during operation. After levelling the machine, secure the feet by tightening the ring nuts with the aid of a screwdriver. Some vibration is inevitable, especially if mounted on a wooden floor. Sprung wooden floors are particularly susceptible to vibration.
Electrical connections Any electrical work required to install this appliance should be carried out by a qualified electrician.or competent person WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliace rating plate(the plate is sticked to the rear of the appliance). The appliance is supplied with a 13 amp plug fitted.
Tricity Bendix, 55-77High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 © Electrolux Household Appliances Limited
