OPERATING & INSTALLATION INSTRUCTIONS FREEZER TB 17 TF 200362933 A/T/4-5. (04.
This instruction book contains safety precautions, hints, information on use and helpful hints and tips. To ensure you use this appliance effective and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference. The symbols below help you to find things more easily: Safety precautions Warnings and Safety information Hints, useful information Environmental information From the Electrolux Group. The world's No.1 choice.
IMPOR TANT S AFET Y INS TR UCTIONS These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department. Prior to installation Check the appliance for transport damage. Under no circumstances should a damaged appliance be installed. In the event of damage please contact your retailer.
CONTENT S Instructions for the User Instructions for the Installer Guide to use the instruction book 2 Technical data 12 Important Safety Instructions 3 Instructions for the User General Information Description of the Appliance, main parts 5 5 5 Installing the Appliance Transportation, Unpacking Location Ventilation Requirements 12 12 12 13 Using the Appliance Before Use To Start the Appliance Thermostat Control Freezing Fresh Food Frozen Food Storage Thawing Making Ice Cubes 6 6 6 6 6 6 6 6 D
INS TR UCTIONS F OR THE USER General information This appliance is designed for freezing and storage of frozen food in a domestic home. To ensure correct operation, the appliance should be located where the ambient temperature is between 16-32 °C. Description of the Appliance, main parts 10 1 11 2 12 9 3 4 5 6 7 8 13 1. Freezing compartment 8. Door gasket 2. Rating Plate 9. Thermostat 3. Storing compartment 10. Condenser 4. Freezing shelf 11. Air circulation 5. Defrost water outlet 12.
Using the Appliance Frozen Food Storage Before Use When first starting the freezer or if the freezer has been out of use for some time, we advise you to run your appliance for at least 4 hours with the thermostat control in the 'Super' position before storing frozen food. Remove all packaging and securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0,5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly.
Hints & Tips Food Storage To obtain the best performance from your freezer: Do not store warm food or evaporating liquid. Avoid buying frozen food if you cannot store it straight away. The use of an insulated container is advisable. When you arrive home, place the frozen food in the freezer immediately. Do not push food together too much, try to allow air to circulate around each item. Do not store food uncovered.
Maint enance & Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Internal Cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5 ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER use detergents, abrasive powders, highly perfumed cleaning products or wax polishes to clean the interior as these will damage the surface and leave a strong odour.
Defrosting 3. Leave the door open. The freezer compartment will become progressively covered with frost. This should be removed with the special plastic scraper provided whenever the thickness of frost exceeds 1/4. 5. When defrosting is completed, dry the interior thoroughly. During this operation it is not necessary to switch off the power supply or to remove the foodstuffs.
Ser vice and Spar e P ar ts In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Tricity Bendix Service Force Centre by telephoning: 08705 929929 Your call will be routed the Service Force Centre covering your post code area. Before calling out an engineer, please ensure you have read the details under the heading Something Not Working.
Guar ant ee Conditions We Tricity Bendix undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electrical supply stated on the rating plate.
Ins tr uctions f or the Ins t aller Model Gross capacity (l) Net capacity (l) Width (mm) Height (mm) Depth (mm) Energy consumption (kWh/day) (kWh/year) Energy class, according to EU Standards Freezing capacity (kg/24h) Rising time (h) Rated power (W) Weight (kg) TB 17 TF 50 50 525 520 587 0.68 248 B 7 17 85 25 Installing the appliance Transportation, unpacking The appliance and the interior fitting are protected for transport. Remove all packaging and any adhesive tape.
Ventilation Requirements The appliance must have adequate ventilation to ensure correct operation. Diagram shows the ventilation requirements when installed: A* Under a worktop, or cupboard. * The clearance space of 10 cm above the appliance may be reduced to 5 cm providing a clearance space 2.5 cm is left on either side of the appliance.
Electrical Connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. The appliance is supplied with a 13 amp plug fitted.
2004. 03. 14. ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE From the Electrolux Group. The worlds No.1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world. Printed by Xerox Hungary Ltd.
