OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO.
TECHNICAL DETAILS MODEL NO. SIE 514 Voltage: 230/240 Volts AC 50Hz Wattage: 9.9/10.8kW Height: 900mm Width: 600mm Depth: 598mm Weight: 65kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC.
CONTENTS Technical Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONTENTS Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Uses of Defrost Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Selecting Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PREFACE Dear Customer, Thank you for buying a Tricity Bendix appliance. With our 80 years experience in developing and manufacturing the very best in U.K. cookers, you can be assured that you have purchased a hard working, reliable, quality product. Tricity Bendix cookers comply with British Standard safety and performance requirements. They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee.
SAFETY After installation, please dispose of the packaging with due regard to safety and the environment, your local authority can arrange this. THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. DURING OPERATION PLEASE READ CAREFULLY Do not use this appliance if it is in contact with water. Never operate it with wet hands. BEFORE INSTALLATION This appliance is designed to be operated by adults.
Take care to follow the recommendations given for tending the food when grilling. Do not leave utensils containing foodstuffs, e.g. fat or oil in or on the appliance in case it is inadvertently switched ON. Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position. Cookers and hobs become very hot, and retain their heat for a long period of time after use. Children should be kept well away from the appliance until it has cooled.
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED The cable should be routed away from potentially hot areas marked by X in the diagram below. RATING PLATE Record the model, product and serial numbers on the back cover from the rating plate. This is situated on the lower front frame of the appliance and can be seen upon opening the top oven door. REAR VIEW The appliance must be protected by a suitably rated fuse or circuit breaker. The rating of the appliance is given on the rating plate.
THE COOLING FAN FOR THE CONTROLS Note: Vapours from the oven vents may in time cause discoloration of wallcoverings behind the appliance. For ease of cleaning it may be preferable to tile behind the appliance. The cooling fan operates immediately when the grill or top oven is switched on. It may run on after the controls are switched off until the appliance has cooled. Note: The action of the cooling fan will depend on how long the top oven or grill have been used and at what temperature.
GRILL AND OVEN FURNITURE The following items of grill and oven furniture have been supplied with the appliance. If you require replacements of any of the items listed below, please contact your local Service Force Centre quoting the relevant part number. 1 grill pan (311409401) 1 grill pan handle (311468100) Note If you require an additional handle for your grill pan, this can be ordered from your local Service Force Centre by quoting part number 311479800\6.
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL A B D C E FEATURES A B C D E F G - G F Timer Oven Temperature Control Oven Indicator Neon Top Oven Temperature Control Top Oven Indicator Neon Selector Control Hotplate Controls 11
THE ELECTRONIC MINUTE MINDER - Button 1 = ( ) Decrease control and minute minder setting button Button 2 = (+) Increase control ( Bell symbol ) Bell Symol The electronic minute minder can also be used to show the time of day. Please note that this is a 24 hour clock, for example 2pm is shown as 1400. In the following pages we explain how to use the minute minder and set the time of day. Read through them until you are familiar with the procedure.
3. To cancel the minute minder If you change your mind and want to cancel the minute minder. Press and release button (1). Press and hold button (1) and the display will countdown in one minute intervals to 0.00. Release button (1) After a few seconds the time of day will show in the display.
THE CERAMIC HOB CAUTION: DO NOT USE THE APPLIANCE IF THE CERAMIC GLASS IS DAMAGED. IF A FAULT OR CRACK BECOMES VISIBLE DURING COOKING, DISCONNECT THE APPLIANCE IMMEDIATELY FROM THE ELECTRICITY SUPPLY AND CONTACT YOUR LOCAL SERVICE FORCE CENTRE. USING THE HOB l l NOTE To operate the hotplates, turn the control knob in either direction to vary the heat setting. The highest number represents the hottest setting and the lowest number the coolest setting.
l Turn the food if necessary; doughnuts float to the surface so will not brown on the upperside if not turned. Once cooked, drain the food on absorbent paper. To prolong the life of hotplates:- l Never use utensils with a skirt, e.g. a bucket. l Never use an asbestos mat. 5. Double frying chips l Never leave the hotplates ON when not Double frying will ensure good chips. First fry the chips for a few minutes at 170°C/340°F to seal the outside. Remove the chips from the oil.
should be allowed to cool before potting to THE GRILL prevent the peel rising. USES OF THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL l l l l Slide the handle to the left and over the central bump on the grill pan. Select the grill function for full grill Select the grill function for centre section only Turn the temperature control knob to the right as far as it will go. This is the hottest setting.
To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to attend to food during cooking or the carrier shelf can be lifted away from the appliance and rested on a heat resistant work surface. NOTE If you require an additional handle for your grill pan, this can be ordered from your local Service Force Centre by quoting part number 311479800\6.
THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking on one level and for small quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche. The top oven is also ideal for use as a warming compartment to warm dishes and keep food hot. Use a temperature setting of 80° - 100°C on the top oven control dial.
l HINTS AND TIPS l l l Most cooking should be carried out using an oven shelf positioned in one of the shelf runners. Larger roasts and casseroles should normally be cooked in the main oven. However, they may be cooked on a flat shelf placed on the base of the top oven provided there is sufficient room for air circulation around the food. l Stand dishes on a suitably sized baking tray on the shelf to prevent spillage onto the oven base and to help reduce cleaning.
THE MAIN FAN OVEN USES OF THE FAN OVEN The oven is heated by an element around the fan situated behind the back panel. The fan draws air from the oven and the element heats the air which circulates in the oven via the vents in the back panel. The advantages of fan oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times.
l HINTS AND TIPS l l l l Arrange the shelves in the required positions before switching the oven ON. Shelves are numbered from the bottom upwards. When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. l When batch baking one type of food, e.g. Victoria sandwich cakes, those of similar size will be cooked in the same time.
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10° C to suit individual preferences and requirements.
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES Rare : 50-60°C; Medium : 60-70°C; Well done:70-80°C MEAT SECOND/FAN OVEN COOKING TIME Beef 160-180°C 20-35 min per ½kg/1lb and 20-35 min over Beef, boned 160-180°C 20-35 min per ½kg/1lb and 25-35 min over Mutton and Lamb 160-180°C 25-35 min per ½kg/1lb and 25-35 min over Pork and Veal 160-180°C 30-40 min per ½kg/1lb and 30-40 min over Ham 160-180°C 30-40 min per ½kg/1lb and 30-40 min over Chicken 160-180°C 15-20 min per ½kg/1lb and 20
DEFROSTING Small or thin fish fillets, frozen peeled prawns, cubed or minced meat, liver, thin chops, steaks etc., can be thawed in 1 - 2 hours. USES OF DEFROST FEATURE This main oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones etc. A 1kg/2¼lb oven ready chicken will be thawed in approximately 5 hours.
CARE AND CLEANING BEFORE CLEANING THE APPLIANCE, ALWAYS ALLOW THE COOLING FAN TO COOL THE APPLIANCE DOWN BEFORE SWITCHING OFF THE ELECTRICITY SUPPLY. If Hob Brite is unavailable, one or more of the cleaning agents below may be used temporarily: a) Cif Cream Cleaner b) Baking Soda CLEANING MATERIALS TO REMOVE MORE STUBBORN MARKS 1. Bar-Keepers Friend may be used to clean off more stubborn stains or to remove discolourations. It may be necessary to rub the marks hard for several minutes. 2.
CLEANING THE OUTSIDE OF THE APPLIANCE HINTS AND TIPS TO REDUCE HOB SOILAGE: l l l l l DO NOT use abrasive cleaning materials eg Hob Brite, Brillo pads or scourers on painted or printed finishes as damage may occur. Regularly wipe over the control panel, oven doors and appliance sides using a soft cloth and liquid detergent. Make sure the bottom of the saucepan and the cooking area are clean and dry before cooking begins. Ensure saucepans are large enough accommodate food to avoid boil overs.
l The vitreous enamel top oven, grill compartment and the fan oven base can be cleaned using normal oven cleaners or aerosol oven cleaners with care. Ensure that the manufacturers instructions are followed and that all parts are well rinsed afterwards. l Aerosol cleaners must not be used on Stayclean surfaces and must not come into contact with the elements or the door seal as this may cause damage. It is NOT necessary to add water to a meat tin when roasting.
REPLACING THE OVEN LIGHT BULB 3. Hold the door glass securely in place with one hand before removing the screws completely with the other hand. The type of bulb required is a 300°C 25 watt small Edison Screw. Part number 572 491 5431-00/1. (Available through Service Centres). 4. Using both hands, gently tilt the top of the door glass towards you, lift slightly to disengage the locators from the two bottom brackets. CAUTION: Disconnect the appliance from the electricity supply before replacing the bulb.
SOMETHING NOT WORKING? The hotplates and ovens work but the grill does not: We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. * Check that you have carefully followed the instructions for operation of the grill.
SERVICE AND SPARE PARTS In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Service Force Centre by telephoning: Before calling out an engineer, please ensure you have read the details under the heading 'Something Not Working'. 0870 5 929929 When you contact the Service Centre you will need to give the following details: Your call will be routed to the Service Force Centre covering your post code area.
To contact your local Service Force Centre telephone CHANNEL ISLANDS GUERNSEY Guernsey Electricity PO Box 4 Vale , Guernsey Channel Islands GY1 3AD JERSEY Jersey Electricity Company Haut de L'orme Rue De Haut De L'orme Trinity Jersey Channel Islands JE3 5FG ISLE OF LEWIS ND Macleod 16 James Street Stornoway Isle of Lewis PA87 2QW 08705 929 929 NORTH EAST GATESHEAD Unit 356a Dukesway Court KELSO 2, 6 & 8 Woodmarket Kelso Borders TD5 7AX Dukesway Gateshead NE11 0BH GRIMSBY 15 Hainton Avenue Grims
To contact your local Service Force Centre telephone MIDLANDS BIRMINGHAM 66 Birch Road East BRIDGNORTH Bridge Road Birmingham Kent BR3 1QZ Ashford CHELMSFORD Bourne Chelmsford Redfields Ind. Estate PE10 9HT Essex Church Crookham CM12 3AE Fleet 68 St.
GUARANTEE CONDITIONS Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: l The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
NOTES SIE 514 - 311537906 34
NOTES 35
RATING PLATE REFERENCE MAKE AND MODEL NO. SERIAL NO. PRODUCT NO. DATE OF PURCHASE IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
