OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO.
TECHNICAL DETAILS MODEL NO. SIE 401 Voltage: 230/240 Volts AC 50Hz Wattage: 11.4/12.4 kW Height: 900mm Width: 550mm Depth: 600mm This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC.
CONTENTS Please refer to the sections in this book which are appropriate to the features on your model. Technical Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Preface . . . . . . . . . . . . . . .
Oven Cooking Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 CONTENTS Roasting Chart 4 Defrost Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PREFACE Dear Customer, Thank you for buying a Tricity Bendix cooker. With our 80 years experience in developing and manufacturing the very best in U.K. cookers, you can be assured that you have purchased a hard working, reliable, quality product. Tricity Bendix cookers comply with British Standard safety and performance requirements. They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee.
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance, has been removed before the appliance is used. If the cooker is to be placed on a base, measures must be taken to prevent the cooker slipping from the base.
Always use oven gloves to remove and replace food in the oven. Ensure that all vents are left unobstructed to ensure ventilation of the oven cavity. Ensure that the anti-tilt shelves are put in place correctly. Refer to instructions on page 15 and 18. Never line any part of the appliance with aluminium foil. Always stand back from the appliance when opening the oven door to allow any build up of steam or heat to release. Do not place sealed cans or aerosols inside the oven.
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE The cable should be routed away from potentially hot areas marked by X in the diagram below. Record the model, product and serial numbers on the back cover of this instruction book, from the rating plate. This is situated on the lower front frame of the appliance and can be seen upon opening the oven door. The appliance must be protected by a suitably rated fuse or circuit breaker. The rating of the appliance is given on the rating plate.
Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. The cooling fan may run on after the control knobs have been switched off until the cooker has cooled. Do not switch the cooker off at its power point until the cooling fan has cooled the cooker down.
GETTING TO KNOW YOUR COOKER THE CONTROL PANEL A B C FEATURES A B C D E F 10 - Main Oven Temperature Control Top Oven Temperature Control Main Oven Indicator Neon Dual Grill Control Top Oven Indicator Neon Hotplate Controls D E F
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates, and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. l l To operate the hotplates turn the control knobs in either direction to vary the heat setting.
DEEP FAT FRYING 6. Frying temperatures Celsius Fahrenheit Scale (oC) Scale (oF) SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one-third full of oil, DO NOT cover the pan with a lid and DO NOT leave the pan unattended. In the unfortunate event of a fire, switch OFF at the electricity supply and cover the pan with a lid or damp cloth to assist in smothering the flames. DO NOT use water on the fire. Leave the pan to cool for at least 30 minutes before moving it.
THE DUAL GRILL USES OF THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes, the centre section only can be used when cooking smaller quantities of food. SELECTING THE GRILL l l To operate the dual grill, turn the grill control clockwise for full area grilling, and anti-clockwise for centre section grilling only.
HINTS AND TIPS l l l l l l l l GRILLING CHART In order to become acquainted with the performance of the Dual Grill it is advisable to check food regularly when grilling. FOOD SHELF GRILL TIME (mins) Bacon Rashers 1 2-3 each side Food should be thoroughly dried before grilling to minimise splashing. Brush lean meats and fish lightly with a little oil or melted butter to keep them moist during cooking.
THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking on one level and for smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche. The top oven is also ideal for use as a warming compartment to warm dishes and keep food hot. Use a temperature setting of 80-100°C on the top oven control dial.
HINTS AND TIPS l l l l Most cooking should be carried out using an oven shelf positioned in one of the shelf runners. Larger roasts and casseroles should normally be cooked in the main oven. However, they may be cooked on a flat shelf from the main oven placed on the base of the top oven provided there is sufficient room for air circulation around the food. Stand dishes on a suitably sized baking tray on the shelf to prevent spillage onto the oven base and to help reduce cleaning.
THE MAIN FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating, however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés, etc., best results are achieved if the oven is preheated first. For best results when cooking frozen or cooked chilled ready meals always preheat the oven first.
TO FIT THE MAIN OVEN SHELVES l The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. HINTS AND TIPS l l l l Arrange the shelves in the required positions before switching the oven ON. Shelves are numbered from the bottom upwards.
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10° C to suit individual preferences and requirements. FAN OVEN FOOD SHELF POSITION Biscuits Bread Bread rolls/buns Cakes: Shelf Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit Christmas Gingerbread Meringues Flapjack Shortbread Casseroles: Beef/lamb Chicken Convenience Foods Fish Fish Pie (Potato Topped) Fruit Pies, Crumbles Milk Puddings Pasta, Lasagne etc.
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES Rare : 50-60°C; Medium : 60-70°C; Well done :70-80°C MEAT SECOND/FAN OVEN COOKING TIME Beef 160-180°C 20-35 min per ½kg/1lb and 20-35 min over Beef, boned 160-180°C 20-35 min per ½kg/1lb and 25-35 min over Mutton and Lamb 160-180°C 25-35 min per ½kg/1lb and 25-35 min over Pork and Veal 160-180°C 30-40 min per ½kg/1lb and 30-40 min over Ham 160-180°C 30-40 min per ½kg/1lb and 30-40 min over Chicken 160-180°C 15-20 min per ½kg/1lb and 20
DEFROST FEATURE USES OF DEFROST FEATURE This fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones etc. It is preferable to thaw fish, meat and poultry slowly in the fridge. However, this process can be accelerated by using the defrost function.
CARE AND CLEANING BEFORE CLEANING ALWAYS ALLOW THE COOLING FAN TO COOL THE APPLIANCE DOWN BEFORE SWITCHING OFF AT THE ELECTRICITY SUPPLY. CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. Cleaners that contain bleach should NOT be used as they may dull the surface finishes. Harsh abrasives should also be avoided. Multi-surface anti bacterial products should not be used on the surrounding trims.
CLEANING THE GRILL PAN, GRILL PAN GRID AND OVEN SHELVES HINTS AND TIPS l All removable parts, except the grill pan handle can be washed in the dishwasher. The grill pan and oven shelves may be cleaned using a soap impregnated steel wool pad. The grill pan grid should be cleaned using hot soapy water. Soaking first in soapy water will make cleaning easier.
SOMETHING NOT WORKING? Before calling an Engineer please carry out the following checks, you may be able to solve the problem without the expense of an engineer. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. If the oven is not cooking evenly or the side opening door will not stay open: * Check that the cooker is level.
SERVICE AND SPARE PARTS In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Tricity Bendix Service Force Centre by telephoning: 0870 5 929929 Your call will be routed to the Service Force Centre covering your post code area. The address of your local Service Force Centre is detailed in the accompanying Customer Care Book.
TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Centre telephone CHANNEL ISLANDS ORKNEY Corsie Domestics (M65) 7 King Street 0870 5 929929 NORTH EAST Kirkwall Orkney KW15 GUERNSEY Guernsey Electricity JERSEY Hydro Electric GATESHEAD Unit 356a PO Box 4 Inveralmond House (M39) Dukesway Court Vale , Guernsey Ruthervenfield Road Dukesway Channel Islands Perth PH1 3AQ Team Valley Jersey Electricity PERTH PERTH Gateshead Graham Begg NE11 0BH Company Unit 4
TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Centre telephone MIDLANDS 0870 5 929929 LONDON & EAST ANGLIA BIRMINGHAM 66 Birch Road East, BECKENHAM 11a (M18) Wyrley (M79) Estate Road Industrial Gardener Indust SOUTH EAST ASHFORD Unit 2 (M58) Bridge Road Business Estate Kent House Lane Witton Beckenham Bridge Road Kent BR3 1QZ Ashford Birmingham B6 7DB Estate Kent CHELMSFORD Hanbury Road (M47) Widford Ind Estate TN2 1BB BOURNE Manning Road Ind Es
GUARANTEE CONDITIONS Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: l The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
SIE 401 311512501
RATING PLATE REFERENCE MAKE AND MODEL NO. PRODUCT NO. SERIAL NO. DATE OF PURCHASE IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This handbook is accurate at the date of printing, but will be superseded and should be disregarded if specifications or appearance are changed. TRICITY BENDIX,55 - 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ TELEPHONE 0870 5 950950 MODEL NO. SIE 401 4 PART NO.
