Pre-Installation Items
%,-70,>.,/04?:8;:909?>1:=$:7::470=>F"=48,=D$0.:9/,=D"$$0042>",20>
I
tem
K
it Components
CPS 500 CPS1000
Quantity
1 Prestige Solo 250 Boiler 2 4
2 2 Boiler Manifold 1 2
3 Hydronic Junction with Insulation & Air Vent 1 1
4 1-1/4” NPT 90° Elbow 1 1
5 1-1/4” NPT x 4” Nipple 7 13
6 Flange - ANSI to 3" NPSC 2 2
7 Flange - ANSI to Blind 2 2
8 Gasket - ANSI 6 8
9 Flared Bolt & Nut – Flange (5/8-11 x 3”) 24 32
10 Bolt, Washer & Nut – Boiler Mounting Bracket (5/16-18 x ¾”) 4 8
11 1-1/2” NPT Union/Shut Off Valve Assembly 2 4
12 1-1/2” NPT 90° Street Elbow 4 8
13 1-1/2” NPT x 13” Flexible Hose/Union Assembly 4 8
14 1-1/2” NPT x Close Nipple 2 4
15 1-1/4” NPT Union 4 8
16 1-1/4” NPT Drain/Shut Off Valve/Circulator Flange Assembly 2 4
17 Circulator – Grundfos UPS 15-58 2 4
18 Gasket – Circulator 4 8
19 Bolt & Nut - Circulator 8 16
20 1-1/2” NPT Circulator Flange/Shut Off Valve Assembly 2 4
21 Heavy-Duty Concrete Anchors with Washer & Nut 4 8
22 Concrete Drill Bit 1 2
23 1-1/2” NPT & 1 1/4” NPT 90º Reducing Elbow 2 2 4
24 1-1/4” NPT x 1/2” NPT x 1-1/4” NPT Inline Reducing Tee 2 4
25 1/2” NPT Plug 2 4
