Gas Piping
$%! 'F$""
,?@=,7,>"4;0$4E492
Refer to Table 11 for Schedule 40 metallic pipe length
and diameter requirements for natural gas, based on the
total of all PRESTIGE Solo Boiler inputs (divided by
1,000 to obtain cubic feet per hour required).
- Table 11 is based on Natural Gas with a specific
gravity of 0.60 and a pressure drop through the gas
piping of 0.30”w.c.
- For additional gas piping sizing information, refer to
A
NSI Z223.1. For Canadian installations refer to
CAN/CSA B149.1.
"=:;,90,>"4;0$4E492
Contact the local propane gas supplier for recommended
sizing of piping, tanks and 100% lockup gas regulator.
%,-70,>"4;492$4E492F ,?@=,7,>
Length of Pipe in
Feet
Capacity of Schedule 40 Metallic Pipe in Cubic Feet of Natural Gas Per
Hour (based on 0.60 specific gravity, 0.30" w.c. pressure drop)
SCH 40 1-1/4" 1-1/2" 2" 2-1/2" 3"
10 1060 1580 3050 4860 8580
20 726 1090 2090 3340 5900
30 583 873 1680 2680 4740
40 499 747 1440 2290 4050
50 662 1280 2030 3590
75 533 1024 1637 2895
100 877 1400 2470
150 704 1120 1980
200 602 960 1700
250 534 851 1500
300 771 1360
400 660 1170
500 585 1030
600 530 937
700 862
800 802
= Not applicable for multiple Solo 399 Boilers
