Manual

Pre-Installation Items
16
?I>=0.:8809/0/?:49>?,77#0A0=>0#0?@=9B4?3',7A0>?:,77:B1:=4>:7,?4:9:1,949/4A4/@,7-:470=1:=>0=A4.492
BEST PRACTICE
Item Kit Components
CRR800 CRR1200 CRR1600 CRR2000
Quantity
1 Prestige Solo 399 Boiler 2 3 4 5
2
2 Boiler Manifold 1 0 2 1
3 Boiler Manifold 0 1 0 1
3 Flange - ANSI to 3" NPSC 2 2 2 2
4 Flange - ANSI to Blind 2 2 2 2
5 Gasket - ANSI 4 4 6 6
6 Flared Bolt & Nut – Flange (5/8-11 x 3”) 16 16 24 24
7
Bolt, Washer & Nut – Boiler Mounting Bracket
(5/16-18 x ¾”)
4 6 8 10
8 1-1/2” NPT Union 6 9 12 15
9 1-1/2” NPT x 4” Nipple 2 3 4 5
10 1-1/2” NPT 90° Elbow 4 6 8 10
11 1-1/2” NPT x 15” Flexible Hose/Union Assembly 4 6 8 10
12 1-1/2” NPT x Close Nipple 4 6 8 10
13 1-1/2” NPT 90° Street Elbow 2 3 4 5
14 1-1/2” NPT x 13-1/2” Pipe 2 3 4 5
15 1-1/2” NPT x 1/2” NPT x 1-1/2” NPT Inline Reducing Tee 2 3 4 5
16 1/2” NPT Plug 2 3 4 5
17 Heavy-Duty Concrete Anchors with Washer & Nut 4 4 8 8
18 Concrete Drill Bit 1 1 2 2
%
,-70,>.,/04?:8;:909?>1:=$:7::470=>#0A0=>0#0?@=9##$0042>",20>
