Manual
Pre-Installation Items
13
%,-70,>.,/04?:8;:909?>1:=$:7::470=>F"=48,=D$0.:9/,=D"$$0042>",20>
Item Kit Components
C
PS800
C
PS1200
C
PS1600
C
PS2000
Quantity
1 Prestige Solo 399 Boiler 2 3 4 5
2
2 Boiler Manifold 1 0 2 1
3 Boiler Manifold 0 1 0 1
3 Hydronic Junction with Insulation & Air Vent 1 1 1 1
4 1-1/4” NPT 90° Elbow 1 1 1 1
5 1-1/4” NPT x 4” Nipple 1 1 1 1
6 Flange - ANSI to 3" NPSC 2 2 2 2
7 Flange - ANSI to Blind 2 2 2 2
8 Gasket - ANSI 6 6 8 8
9 Flared Bolt & Nut – Flange (5/8-11 x 3”) 24 24 32 32
10 Bolt, Washer & Nut – Boiler Mounting Bracket (5/16-18 x ¾”) 4 6 8 10
11 1-1/2” NPT Union/Shut Off Valve Assembly 2 3 4 5
12 1-1/2” NPT 90° Street Elbow 4 6 8 10
13 1-1/2” NPT x 15” Flexible Hose/Union Assembly 4 6 8 10
14 1-1/2” NPT x Close Nipple 6 9 12 15
15 1-1/2” NPT Union 2 3 4 5
16
1-1/2” NPT Drain/Shut Off Valve/Circulator Flange
Assembly
2 3 4 5
17 1-1/2” NPT 90º Elbow 2 3 4 5
18 1-1/2” NPT x 1/2” NPT x 1-1/2” NPT Inline Reducing Tee 2 3 4 5
19 1/2” NPT Plug 2 3 4 5
20 Circulator – Grundfos UPS 26-99FC 2 3 4 5
21 Gasket – Circulator 4 6 8 10
22 Bolt & Nut - Circulator 8 12 16 20
23 1-1/2” NPT Circulator Flange/Shut Off Valve Assembly 2 3 4 5
24 Heavy-Duty Concrete Anchors with Washer & Nut 4 4 8 8
25 Concrete Drill Bit 1 1 2 2
