User Manual

Page 3 Bandit VXL (Model 2407) Parts List
REV. 100127 1631
2458A
Springs, front (white) (2) ....................................................................
$4.00
2457
Springs, rear (black) (2) ...............................................
$2.00
2457A
Springs, rear (white) (2) .....................................................................
$4.00
3760
Ultra Shocks (black) (long) (complete w/ spring pre-
load spacers & springs) (front) (2) .................................
$18.00
3762
Ultra Shocks (black) (xx-long) (complete w/ spring pre-
load spacers & springs) (rear) (2) ..................................
$18.00
3760A
Ultra Shocks (grey) (long) (complete w/ spring pre-load spacers &
springs) (2) .........................................................................................
$18.00
3762A
Ultra Shocks (grey) (xx-long) (complete w/ spring pre-load
spacers & springs) (rear) (2) ..............................................................
$18.00
Slipper Clutch Components
3793
Input shaft (slipper shaft) / spring pin.................................................
$3.00
5552
Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring/ pin/
4.0mm NL) .........................................................................................
$8.00
2554
Screws, 3x6mm cap-head machine (hex drive) (6) ...........................
$2.50
5556
Slipper pressure plate & hub (aluminum alloy) ..................................
$8.00
Spur Gears & Pinion Gears
2416
Gear, 16-T pinion (48-pitch) / set screw .........................
$3.50
1918
Gear, 18-T pinion (48-pitch) / set screw .........................
$3.00
2419
Gear, 19-T pinion (48-pitch) / set screw .........................
$3.00
2423
Gear, 23-T pinion (48-pitch) / set screw .........................
$3.00
2426
Gear, 26-T pinion (48-pitch)/set screw...............................................
$3.00
2431
Gear, 31-T pinion (48-pitch) / set screw .........................
$3.00
4725
Gear, pinion (25-tooth) (48-pitch) / set screw .................
$3.00
4728
Gear, pinion (28-tooth) (48-pitch)/ set screw ..................
$3.00
4676
Spur gear, 76-tooth (48-pitch) (for models with Torque-Control
slipper clutch) .....................................................................................
$3.00
4683
Spur gear, 83-tooth (48-pitch) (for models with Torque-
Control slipper clutch) ..................................................
$3.00
4686
Spur gear, 86-tooth (48-pitch) (for models with Torque-
Control slipper clutch) ..................................................
$3.00
4690
Spur gear, 90-tooth (48-pitch) (for models with Torque-
Control slipper clutch) ..................................................
$3.00
Steering Components
2728
Ball bearings (5x8x2.5mm) (2) ......................................
$8.00
2545
Bellcrank bushings (plastic) (5x8x2.5mm) (4)....................................
$3.00
5347
Rod ends, Revo (large) with hollow balls (12) ...................................
$9.00
3744
Servo saver w/ adapters ....................................................................
$4.00
3742
Shoulder screws, steering bellcranks (3x30mm hex cap) (2)/
draglink shoulder screws (chrome) (2)...............................................
$2.00
3743
Steering bellcranks (l&r)/ draglink ......................................................
$4.00
3743A
Steering bellcranks, drag link (blue-anodized T6
aluminum)/ 5x8mm ball bearings (4)
hardware (assembled) ..................................................
$34.00
3743X
Steering bellcranks, drag link (red-anodized T6
aluminum)/ 5x8mm ball bearings (4)
hardware (assembled) ..................................................
$34.00
6845
Steering bellcranks/ servo saver/ servo saver spring/
servo spring retainer/servo horn, steering ......................
$12.00
2445
Turnbuckles, toe link, 55mm (75mm center to
center) (2) (assembled with rod ends and hollow balls).....................
$8.00
Suspension Linkage
5525R
Rod ends, heavy duty (Jato/Slayer) (8) .............................................
Call
5347
Rod ends, Revo (large) with hollow balls (12) ...................................
$9.00
3744
Servo saver w/ adapters ....................................................................
$4.00
2637
Suspension pins, 31.5mm, chrome (2) w/ E-
clips (4) (front suspension arm to caster block) ..............
$2.50
2640
Suspension pins, 44mm (2) w/ E-clips ...............................................
$2.50
3640
Suspension screw pin set, steel (hex drive) (requires part # 2640
for a complete suspension pin set) (Rustler, Stampede, Bandit).......
$4.50
2443
Turnbuckles, camber link, 36mm (56mm center to
center) (rear) (assembled with rod ends and hollow balls) (1 left,
1 right)................................................................................................
$7.00
2444
Turnbuckles, camber link, 47mm (67mm center to
center) (front) (assembled with rod ends and hollow balls) (1 left,
1 right) ...............................................................................................
$7.00
2445
Turnbuckles, toe link, 55mm (75mm center to
center) (2) (assembled with rod ends and hollow balls).....................
$8.00
Team Traxxas Items
5840
Camera, video (Go Pro R/C Hero with mounts and
waterproof housing) .....................................................
$340.00
2514
Decal sheet, racing sponsors ........................................
$3.00
6160X
DVD, Maxx Power! Full Throttle Action (sleeve) ..............
$12.99
9950
Official Team Traxxas racing decal set (flag logo/ 6-
color) ..........................................................................
$4.50
9909
Traxxas racing banner, red & black (3x7 feet) ................
$15.00
Tires & Wheels
3647
Nuts, 4mm flanged nylon locking (steel, serrated) (8) ......................
$3.25
1647
Silicone grease ..................................................................................
$2.00
2754
Stub axle pins (4)...............................................................................
$1.00
1985
Teflon washers, 5x8x0.5mm (20) (use with ball bearings) ................
$2.00
2470A
Tires & wheels, assembled (Tracer 2.2" black chrome wheels,
Alias 2.2" tires) (2) (Bandit rear, medium compound with foam
inserts) ...............................................................................................
$26.00
2471A
Tires & wheels, assembled (Tracer 2.2" black chrome wheels,
Alias ribbed 2.2" tires) (2) (Bandit front, medium compound w/
foam inserts) ......................................................................................
$24.00
2479A
Tires & wheels, assembled (Tracer 2.2" black chrome
wheels, Anaconda 2.2" tires with foam
inserts) (2) (Bandit front) ..............................................
$24.00
2478A
Tires & wheels, assembled (Tracer 2.2" black chrome
wheels, Anaconda 2.2" tires with foam
inserts) (2) (Bandit rear) ...............................................
$27.00
2470R
Tires & wheels, assembled (Tracer 2.2" chrome
wheels, Alias 2.2" tires) (2) (Bandit rear, soft
compound with foam inserts) .........................................
$25.00
2471R
Tires & wheels, assembled (Tracer 2.2" chrome
wheels, Alias ribbed 2.2" tires) (2) (Bandit front, soft
compound w/ foam inserts) ...........................................
$23.00
2479R
Tires & wheels, assembled (Tracer 2.2" chrome
wheels, Anaconda 2.2" tires with foam
inserts) (2) (Bandit front) ..............................................
$23.00
2478R
Tires & wheels, assembled (Tracer 2.2" chrome
wheels, Anaconda 2.2" tires with foam
inserts) (2) (Bandit rear) ...............................................
$26.00
4740
Tires, 2.1" Pro-Trax ribbed (front) (2) ............................
$8.00
1771
Tires, 2.1" spiked (front) (2) ..........................................
$8.00
1770
Tires, 2.15 spiked (rear) (2) .........................................
$10.00
2470
Tires, Alias 2.2" (rear) (2)/ foam inserts (Bandit) (soft
compound) ..................................................................
$15.00
2471
Tires, Alias ribbed 2.2" (wide, front) (2)/ foam
inserts (Bandit) (soft compound) ...................................
$14.00
2478
Tires, Anaconda 2.2" (rear) (2)/ foam
inserts (Bandit) (soft compound) ...................................
$16.00
2479
Tires, Anaconda 2.2" (wide, front) (2)/foam
inserts (Bandit) (soft compound) ...................................
$14.00
3471
Tires, street slicks (front) (2) ........................................
$10.00
3470
Tires, street slicks (rear) (2) .........................................
$11.00
2475
Wheels, front (2) ..........................................................
$4.00
2474
Wheels, rear (2) ...........................................................
$4.00
2473A
Wheels, Tracer 2.2" (black chrome) (2) (Bandit front) .......................
$8.50
2472A
Wheels, Tracer 2.2" (black chrome) (2) (Bandit rear)........................
$9.00
2473
Wheels, Tracer 2.2" (chrome) (2) (Bandit front) ..............
$7.50
2472
Wheels, Tracer 2.2" (chrome) (2) (Bandit rear) ...............
$8.00
3685
White plastic washers (5x8x1.0mm) (6).............................................
$2.50
Transmission Components
1552
Backplate screws (3x8mm hex cap) (6)/washers (6)/
wrench ........................................................................
$3.00
4607
Ball bearings (5x11x4mm) (8).......................................
$24.00
5116
Ball bearings, blue rubber sealed (5x11x4mm) (2)............................
$3.50
3792
Dust cover/rubber plug (w/ screws) (Stampede/Rustler/Bandit)........
$3.50
5478
Flat wrench, 8mm (blue-anodized aluminum)....................................
$4.00
3691
Gearbox halves (l&r) (black) w/ idler gear shaft ..............
$8.00
3691A
Gearbox halves (l&r) (grey) w/ idler gear shaft .................................
$8.00
5148
Grease, white lithium .........................................................................
$3.00
1996X
Idler gear, machined-aluminum (not for use with steel
top gear) (hard-anodized) (30-tooth) ..............................
$12.00
3696
Idler gear, steel (30-tooth) .................................................................
$3.00
3793
Input shaft (slipper shaft) / spring pin.................................................
$3.00
2381X
Main diff with steel ring gear/ side cover plate/ screws (Bandit,
Stampede, Rustler)............................................................................
$6.00
2382
Planet gears (4)/ planet shafts (4)/ sun gears (2)/sun gear
alignment shaft (1) all hardened steel................................................
$6.00
2388X
Planetary gear differential with steel ring gear (complete) (fits
Bandit, Stampede, Rustler)................................................................
$15.00
3931
Screws, 3x8mm flat-head machine (hex drive) (6) ............................
$2.50
3185X
Screws, 3x8mm washerhead machine (large head for motor
mount) (6) .........................................................................................
$1.50
1647
Silicone grease ..................................................................................
$2.00
5556
Slipper pressure plate & hub (aluminum alloy)..................................
$8.00
3195
Top drive gear, steel (22-tooth) .........................................................
$3.00
