Bandit VXL (Model 2407) Parts List
Parts shown in bold are optional accessories. Part categories and indivi d ual part listings are arranged alphabetically. Prices are shown in US Dolla r s.
For assistance call 1-888-TRAXXAS, or e-mail Traxxas anytime at [e-mail] REV. 100127 1631
Bearings & Bushings
4607
Ball bearings (5x11x4mm) (8) ......................................
$24.00
2728
Ball bearings (5x8x2.5mm) (2) ......................................
$8.00
5116
Ball bearings, blue rubber sealed (5x11x4mm) (2) ............................
$3.50
5114
Ball bearings, blue rubber sealed (5x8x2.5mm) (2) .........
$4.00
2545
Bellcrank bushings (plastic) (5x8x2.5mm) (4)....................................
$3.00
1675
Oilite bushings (5x11x4mm) (14) ...................................
$5.00
1985
Teflon washers, 5x8x0.5mm (20) (use with ball bearings).................
$2.00
Body & Accessories
1926
Antenna caps, vinyl (2)/ antenna spool ..........................
$2.00
1726
Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1).................
$1.00
1834
Body clips (12) (standard size) ..........................................................
$2.00
1815
Body washers (8) .........................................................
$2.00
2417
Body, Bandit (front & rear) (clear, requires painting)/ window,
lights, grill decal sheet........................................................................
$20.00
2418
Body, Bandit VXL, ProGraphix (front and rear) (replacement for
the painted body. Graphics are printed, requires paint & final
color application)window, grill, lights decal sheet ..............................
$34.99
2514
Decal sheet, racing sponsors ........................................
$3.00
2413R
Decal sheets, Bandit VXL ..................................................................
$11.00
9950
Official Te am Traxxas racing decal set (flag logo/ 6-
color) ..........................................................................
$4.50
5185
Tires, rubber (2) (fits Traxxas wheelie bar wheels) .........
$7.00
4974
Wheelie bar arm (1)/ connector (1)/ 3x12 SS (hex
drive) (4) .....................................................................
$10.00
3677
Wheelie bar mount (1)/ hardware (Stampede, Rustler, Bandit
series) ................................................................................................
$4.00
3678
Wheelie bar, assembled (fits Stampede, Rustler,
Bandit series) ..............................................................
$15.00
4976
Wheels (4)/ Axles (2), for Maxx wheelie bar ...................
$4.00
5186A
Wheels, aluminum (blue-anodized) (2)/ 5x8m m ball
bearings (4)/ axles (2)/ rubber tires (2) ..........................
$19.95
5186
Wheels, aluminum (red-anodized) (2)/ 5x8mm ball
bearings (4)/ axles (2)/ rubber tires (2) ..........................
$19.95
2712
Wing...................................................................................................
$2.50
2615
Wing buttons (2)/ set screws (2)/ spacers (2)/ 3x8mm CS (2) ...........
$2.50
2414
Wing wire ...........................................................................................
$2.00
Chassis & Attachments
3725X
Battery expansion kit (allows for installation of taller
multi-cell battery packs) (Rustler, Bandit, Stampede) ......
$6.00
3727
Battery hold-down plate (black)/ metal posts (2)/body
clips (2) ......................................................................
$3.00
3727A
Battery hold-down plate (grey) / metal posts (2) / body clips (2)........
$3.00
3628
Box, receiver (sealed)/ foam pad/2.5x8mm CS (2)/ 3x10mm
CS (2)/ 2.5x10mm CS (2) ..................................................................
$12.00
2735
Bumper (front) ....................................................................................
$3.00
3722
Lower chassis (black)...................................................
$15.00
3722A
Lower chassis (grey)..........................................................................
$15.00
3725
Mounting plate, speed control (VXL-3s) (Bandit, Rustler,
Stampede) .........................................................................................
$3.00
3629
Seal kit, receiver box (includes o-ring, seals, and silicone grease) ...
$4.00
5185
Tires, rubber (2) (fits Traxxas wheelie bar wheels) .........
$7.00
3723
Upper chassis (black)...................................................
$5.00
3723A
Upper chassis (grey)..........................................................................
$5.00
4974
Wheelie bar arm (1)/ connector (1)/ 3x12 SS (hex
drive) (4) .....................................................................
$10.00
3677
Wheelie bar mount (1)/ hardware (Stampede, Rustler, Bandit
series) ................................................................................................
$4.00
3678
Wheelie bar, assembled (fits Stampede, Rustler,
Bandit series) ..............................................................
$15.00
4976
Wheels (4)/ Axles (2), for Maxx wheelie bar ...................
$4.00
5186A
Wheels, aluminum (blue-anodized) (2)/ 5x8m m ball
bearings (4)/ axles (2)/ rubber tires (2) ..........................
$19.95
5186
Wheels, aluminum (red-anodized) (2)/ 5x8mm ball
bearings (4)/ axles (2)/ rubber tires (2) ..........................
$19.95
Differential Components
2381X
Main diff with steel ring gear/ side cover plate/ screws (Bandit,
Stampede, Rustler) ............................................................................
$6.00
2382
Planet gears (4)/ planet shafts (4)/ sun gears (2)/sun gear
alignment shaft (1) all hardened steel................................................
$6.00
2388X
Planetary gear differential with steel ring gear (complete) (fits
Bandit, Stampede, Rustler)................................................................
$15.00
1647
Silicone grease ..................................................................................
$2.00
Driveline Components
4628R
Differential output yokes, black (2)/ 3x5mm countersunk
screws (2)/ screw pin (2)....................................................................
$4.00
4628X
Differential output yokes, hardened steel (w/ U-
joints) (2) ....................................................................
$19.50
2751
Half-shaft pro-pack (internal-splined (6)/external-
splined (6)) (plastic shafts only) ....................................
$10.00
1651
Half-shafts (internal-splined (2)/external-splined (2))/ metal U-
joints (4) .............................................................................................
$6.00
3752
Stub axle carriers (2) (requires 5x11x4mm bearings)........................
$3.00
3652A
Stub axle carriers, Rustler/Stampede/Bandit (2), 6061-
T6 aluminum (blue-anodized)/ 5x11mm ball
bearings (4) .................................................................
$35.00
3652X
Stub axle carriers, Rustler/Stampede/Bandit (2), 6061-
T6 aluminum (red-anodized)/ 5x11mm ball bearings (4) ...
$35.00
2754
Stub axle pins (4)...............................................................................
$1.00
2753X
Stub axles, rear (2) ............................................................................
$5.00
Front Suspension & Steering
2728
Ball bearings (5x8x2.5mm) (2).......................................
$8.00
2545
Bellcrank bushings (plastic) (5x8x2.5mm) (4)....................................
$3.00
2530
Bulkhead (front) (black) ................................................
$6.00
2530A
Bulkhead (front) (grey).......................................................................
$6.00
2432
Caster blocks (l&r) (30-degree) .........................................................
$4.00
3632A
Caster blocks, 30-degree, blue-anodized 6061-T6
aluminum (left & right) ..................................................
$24.00
3632X
Caster blocks, 30-degree, red-anodized 6061-T6
aluminum (left & right) ..................................................
$24.00
2437
Front axles (2)....................................................................................
$3.00
5525R
Rod ends, heavy duty (Jato/Slayer) (8) ..........................
Call
5347
Rod ends, Revo (large) with hollow balls (12) ...................................
$9.00
3646
Screws, 3x15mm flat-head machine (hex drive) (6) ..........................
$2.50
3744
Servo saver w/ adapters ....................................................................
$4.00
3639
Shock tower (front) ............................................................................
$4.00
3736
Steering blocks, left & right (2) (requires 5x11x4mm bearings) ........
$3.00
3636A
Steering blocks, Rustler/Stampede/Bandit (2), 6061-T6
aluminum (blue-anodized)/ 5x11mm ball bearings (4) ......
$35.00
3636X
Steering blocks, Rustler/Stampede/Bandit (2), 6061-T6
aluminum (red-anodized)/ 5x11mm ball bearings (4) .......
$35.00
2531X
Suspension arms (front) (2) ...............................................................
$11.00
2640
Suspension pins, 44mm (2) w/ E-clips...............................................
$2.50
3640
Suspension screw pin set, steel (hex drive) (requires part # 2640
for a complete suspension pin set) (Rustler, Stampede, Bandit).......
$4.50
2537
Threaded rods (20/25/44mm 1 ea.)/ (1) 12mm set screw .................
$2.50
2532
Tie bar, fiberglass ..............................................................................
$4.00
2444
Turnbuckles, camber link, 47mm (67mm center to
center) (front) (assembled with rod ends and hollow balls) (1 left,
1 right) ...............................................................................................
$7.00
2445
Turnbuckles, toe link, 55mm (75mm center to
center) (2) (assembled with rod ends and hollow balls) ....................
$8.00
Hardware
1834
Body clips (12) (standard size) ..........................................................
$2.00
3934
Body clips, heavy duty (12)................................................................
$3.00
2585
Cylinder head bolts, marine 3x20mm CS (6) (TRX 2.5) ....................
$2.50
2745
Nuts, 3mm nylon locking (12) ............................................................
$2.00
3647
Nuts, 4mm flanged nylon locking (steel, serrated) (8) ......................
$3.25
1747
Nuts, 4mm nylon locking (10) ............................................................
$2.00
1942
Rod ends (16 long & 4 short)/ hollow ball connectors (18)/ ball
screws (2) ..........................................................................................
$7.00
5347
Rod ends, Revo (large) with hollow balls (12) ...................................
$9.00
2742X
Rod ends, short (6)/ hollow balls (6) ..................................................
$4.00
3347
Screws, 2.5x5mm button-head machine (hex drive) (6) ....................
$2.50
3215
Screws, 2.5x6mm cap-head machine (hex drive) (6) ........................
$2.00
2587
Screws, 3x10mm cap-head machine (6) (no washer) .......................
$2.50
2578
Screws, 3x12mm button-head machine (hex drive) (6) .....................
$2.50
2552
Screws, 3x12mm countersunk machine (6) (hex drive).....................
$2.50
2579
Screws, 3x15mm button-head machine (hex drive) (6) .....................
$2.50
2586
Screws, 3x15mm cap-head machine (hex drive) (6) .........................
$2.50
3646
Screws, 3x15mm flat-head machine (hex drive) (6) ..........................
$2.50
2580
Screws, 3x20mm button-head machine (hex drive) (6) .....................
$2.50
2591
Screws, 3x23mm button-head machine (hex drive) (6) .....................
$2.50
2582
Screws, 3x30mm button-head machine (hex drive) (6) .....................
$2.50
2592
Screws, 3x40mm button-head machine (hex drive) (6) .....................
$3.00
2575
Screws, 3x6mm button-head machine (hex drive) (6) .......................
$2.50
2554
Screws, 3x6mm cap-head machine (hex drive) (6) ...........................
$2.50
