5. WIRE TYPES
The following are the minimum specifications for hook-up wire that
should be used during the installation process:
a) Ranger Power and Ground
300V, 105°C PVC, 18AWG stranded
b) Ignition
300V, 105°C PVC, 22AWG stranded
c) Odometer Interface
300V, 105°C PVC, 22AWG stranded
d) Ranger Inputs (i.e. Emergency Input, etc.)
300V, 105°C PVC, 22AWG stranded
6. ELECTRICAL MEASUREMENTS
Always ensure that there is adequate voltage at the point where Ranger is being pow-
ered. Compare this voltage to the voltage at the battery. The two voltages should be
almost the same or a different power point should be chosen closer to the battery.
CABLING
