TORQUE SETTINGS
Thereareanumberofitemsthatmayneedtobeinstalledtoaspecictorquelevel.
This includes the Main Cable Cover, Mounting Ball, RF Cable Cover and antennas.
The following Table lists the recommended torque settings for installing these items.
Over and under torquing can lead to product damage and/or failure.
We recommend using a calibrated torque screwdriver for tightening all screws.
A Huber Suhner SMA torque wrench (74Z-0-0-21) is recommended for tightening
the Antenna cable.
INSTALLING THE RANGER COVER PLATE
Description Trapeze Part Number
Recommended Torque
Oz.In N.cm
Main Cable Cover 3-ENC-RNGRP226-XX 80-90 55-65
Mounting Ball 6-MNT-RAMCMN3X-XX 80-90 55-65
RF Cable Cover 3-ENCRNGRP301-XX 80-90 55-65
R-SMA Antenna Cable 6-ANT-XXXXXXXX-XX 140 100
