Ranger
Ranger Interface Cable
Ranger Power Pigtail
Ranger Mount
In-line Cable Fuse(s)
In-line cable fuse holder. Two holders and fuses
are supplied. The 3 Amp fuse is for power and
the 2 Amp fuse for the igntion input.
SUPPLIED (OPTIONAL)
Emergency switch
NOT SUPPLIED
• Zip Ties
• Glued Heat Shrink
• Tools as Required
• Grommets
• Loom
• Fasteners
Please verify that you have everything that you need to complete the Ranger installation.
NOTE: Not all parts are provided by Trapeze.
SUPPLIED
PARTS LIST
F1
F2
F3
F4
F5
4-CAS-PIGTMMLX20-00
