User's Manual

CAUTIONS

a) Carefully read the Installation Guide before installing this product. If anything is un-

clear please contact Trapeze for support.

b) Ensure that the NEGATIVE battery connection is disconnected before beginning work.

Note: Some components may lose short-term memory (i.e. engine or transmission adap-

tive parameters, and radio presets) after a protracted time without battery power.

c) Ranger should be serviced by qualified, trained personnel only. Attempting to

remove the cover or disassemble the device could expose you to dangerous high

voltage points.

d) Do not attempt to install or operate a damaged device. If the unit has been

exposed to excessive amounts of water; shows evidence of physical damage; or

is not operating properly; unplug it from the power source and contact qualified

service personnel.

e) Use of thread-locking compounds such as Loctite may cause serious damage

to plastic enclosures. Many thread-locking compounds are not compatible with

thermoplastics and can lead to stress cracking. This will require the unit to be

returned to replace the ABS enclosures.

TOUCH PANEL CARE AND CLEANING

• Do not use high-pressure air, water or steam to clean the surface of the touch

panel. The action may cause the touchpanel to mal-function.

• Clean the touch panel surface with a dry soft cloth; only Alcohol or Ammonia

based cleaner can be used with caution when necessary.

• Always dampen the cloth and clean the panel. Do not spray the cleaning agent on

the panel itself

• The touch panel is sensitive to long term water exposure and any excess

moistrue should be wiped off.

• Do not apply adhesive materials to the surface of the touch panel. This can

cause permanent damage. This restriction includes stickers, tape and static

screen protectors.

• The use of aftermarket screen protectors is not recommended and may void

the warranty of the touch panel. A heavy duty film option is available as a

manufacturing option.

Ensure that you have all of the items listed in the Parts List

BEFORE YOU BEGIN
