12.5 Specifications
• Supply Voltage
Typical 12 V or 24V
Min 6 V
Max 32 V
• Current Consumption
Input Voltage (V) Current Draw (mA)
Standby
Idle
4
Typical
5
9 68 360 965
13.8 50 250 645
24 39 160 405
30 19 110 260
Maximum
6
3.0 A
• Operating Temperature
Min -30
o
C Max 65
o
C
• Storage Temperature
Min -30
o
C Max 70
o
C
• Size
8.25" x 2.0" x5.7”
210mm x 57mm x 146mm
• Weight
2.0 lbs / 0.9 kg
• 5% - 95% relative humidity non-condensing
12.5.1 Footnotes
1. Unit is IP54 rated for water.
2. Ranger unit may not be water-resistant when some of the options are specified.
3. USB 2.0 High Speed; one port is for maintenance.
4. When display is off, the unit is idle without modem active.
5. Unit Idle with full backlight with GPS, Wi-Fi and Bluetooth and Modem idle.
6. This is an absolute maximum that includes an installed modem and all peripheral devices. Actual current draw
depends on system design.
Operation at temperatures outside these ranges for extended periods of time is not recommended.
Trapeze reserves the right to change circuitry and specifications without notice at any time. Please ensure that
you have the most recent version of this document.
Only use Trapeze approved cables for installation purposes. Refer to cable section of the Hardware Installation
Manual for additional information.
