Datasheet

For MP-3XX
For MP-422
For MP-522E
For MP-620
For MP-632
PRODUCT PHOTO
VERTICAL GAIN
HORIZONTAL GAIN
Frequency Range
Impedance
VSWR (50 Ohms)
Gain, dBi
Polarization
3dB Beamwidth V
3dB Beamwidth H
Front to Back Ratio
Maximum Power
Connector
Type / Style
Dimensions
Weight
Frontal Wind Loading
Operating Temperature
Storage Temperature
Humidity
Lightning Protection
Mounting Options
Cable
360
0
Omni (2.4 GHz Specs) 360
0
Omni (5 GHz Specs)
ANT-7360P-IN ANT-7360P-IN
INTENTIONALLY LEFT BLANK
INTENTIONALLY LEFT BLANK
INTENTIONALLY LEFT BLANK
2400-2500 MHz 5150-5875 MHz
50 Ohms 50 Ohms
<2 : 1 Max < 2 : 1 Max
3 dBi 5 dBi
Vertical, Linear Vertical, Linear
78 Deg 78 Deg
360 Deg 360 Deg
2W 2W
Female SMA Female SMA
134 x 21 mm 134 x 21 mm
27.5g / 0.66 Lbs 27.5g / 0.66 Lbs
N/A N/A
-20 to +60 Deg C -20 to +60 Deg C
-20 to +60 Deg C -20 to +60 Deg C
95% 95%
N/A N/A
AP Mount AP Mount
N/A N/A
DUAL BAND INDOOR
7/12/2010 Trapeze Networks Antenna Summary.xls 3 of 9
