2.4 GHz Digital Wireless USB Outdoor Camera User's Manual Preliminary Version 2.
.4 GHz Digital Wireless USB Camera Contents 1 Package Content 2 Product Layout USB Receiver Camera 3 PC System Requirements 4 Camera Setup 4.1 Positioning the Camera 4.2 Power Supply 4.3 Fine Tuning 5 Receiver Setup 5.1 Windows Detect & Install New Device 5.2 Driver Installation 5.3 Skype Resident Program Installation 5.4 Monitoring Software 5.
ENGLISH 1. Package Content One Camera One USB Receiver One Power Adapter CD-ROM This User's Manual 2. Product Layout 1 USB Receiver 1. Antenna 2. Camera indicator LEDs 3. Camera switch 4 2 3 / Pairing button* 4. USB plug Note: For Pairing, see section 5.5 1 Camera 1. Antenna 2. Lens 2 3. Infrared LEDs (20 pcs) 3 4. Power indicator LED 5. Mounting bracket 6. Microphone 7. Wing screw 8. Pairing button 8 4 9 6 5 7 9. Power adapter cable 3.
ENGLISH Pentium-IV 1.6GHz or higher (recommended) 256 MB RAM of system memory or higher (recommended) One available USB port (preferably USB2.0) Graphics Card (Must support DirectX 9.0c) Sound Card (AC97 compatible sound card) 1GB Free HD Space CD-ROM Drive (For software installation) 4. Camera Setup 4.1 Positioning the Camera 1. Fix the camera to the wall or ceiling using the masonry plugs and fixing screws supplied. 2. Select a suitable location to drill a cable entry hole.
ENGLISH How to use the waterproof tape After connecting the plug of the power Cable Entry Hole Waterproof Tape adapter to the Power In socket of the camera, use the provided waterproof tape to protect it from moisture and dirt . 1. Remove the release liner and wrap Release Liner the waterproof tape around the plug and socketin a spiral. Wrap the tape with enough tension to obtain conformability on the surface. 2.
ENGLISH 5.1 Windows detect & install new device Make sure the OS of PC is Windows XP and the version is above (or equal) SP2. (Windows Vista is allowable). 1. Insert the USB Receiver into one USB port of PC and the "Found New Hardware wizard" screen will appear. Note: If the device has been searched and the screen isn't showed, please follow 5.2-2. 2. Choose "Install the software auto Driver Installation matically(Recommended)" in this screen and click "Next".
ENGLISH 5.3 Skype resident program installation (Disk 1) You can watch senior citizen or disabled people through Skype from remote location. 1. Please download and setup Skype software from www.skype.com (free software). 2. Insert the provided CD-ROM into your CD-ROM drive of PC and access to D:\RemoteMonitor-Skype\ (Where D is the letter of your CD-ROM drive). 3. Double-click the execution file named "rm_e_s.exe" and the "Welcome to the Remote Monitoring Setup Wizard" screen will appear. 4.
ENGLISH 6. Details on the Skype Resident Program Installation 6.1 Permit remote monitoring program to access Skype At the first launch of Remote Monitoring program, Skype displays a pop-up message asking allow Remote Monitoring program to access Skype. Please click Allow access button to permit Remote Monitoring program to connect to Skype. In case if you click Deny access button, or forgot to click Allow access button, you can enable Remote Monitoring program to access Skype by following steps below. 1.
ENGLISH 3. In the Manage API Access Control dialog box, find program name "SWatch.exe". If the program's state is "Not allowed to use Skype", click Change button. 4. In the dialog box, select the option "Allow this program to use Skype ", and then click OK button to close the dialog box. 5. Click Save button to close the Options dialog box and confirm the setting change. 6.
ENGLISH 1. Enable automatic-answering Skype incoming calls and start Skype video sending Check the option to enable the function of Remote Monitoring. Remote Monitoring program will auto-answer Skype calls and ask for a password to start sending Skype video. 2. Incoming call ringing period before asking password Specify the time length to wait to answer an incoming call. The waiting length can be from 0 to 30 seconds. 3.
ENGLISH 2. Run Skype program and the Remote Monitoring program. 3. Enable the remote monitoring function of Remote Monitoring program. Watch camera video remotely 1. Make a Skype call to the name that hosts the Skype on the computer with camera monitoring the security area. 2. After several ringing, the call will be answered with a chat message asking for a password. 3. If the password you enter is not correct, a chat message will ask you to enter password again. 4.
ENGLISH The following table lists the available commands and their descriptions. Command CAM1 Description Display the video of camera 1 CAM2 Display the video of camera 2 CAM3 Display the video of camera 3 CAM4 Display the video of camera 4 7. Troubleshooting You don't get a signal at all Make sure the camera and the computer are turned on. Make sure the power plugs are pushed all the way in. If the camera is powered by batteries, replace all batteries with new ones.
ENGLISH 8. Care and Maintenance Do not store in very cold areas. When the system warms up (to its normal temperature), moisture can form inside the case, which may damage electronic circuit boards. Do not attempt to open the case. Non-expert handling of the device may damage the system. Avoid dropping or strong shocks. Operate this product using only with the power supply included or provided as an accessory. Do not overload electrical outlets or extension cords this can result in fire or electric shocks.
ENGLISH Caution: For Camera 1. To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. 2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter For Dongle The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment, under 47 CFR 2.1093 paragraph (d)(2). The 2.
